| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
|
[1] |
Injection pump
|
|
| 2. |
|
[1] |
Inj timing dvc
|
|
| 3. |
VOE478721
|
[1] |
Oil feed pipe
|
|
| 4. |
VOE13947282
|
[3] |
Gasket
|
|
| 5. |
|
|
Oil feed pipe
|
|
| |
|
|
Hollow screw
|
|
| 6. |
|
|
Turbocharger
|
|
| 7. |
VOE13947282
|
[3] |
Gasket
|
|
| 8. |
VOE13947975
|
[1] |
Hollow screw
|
|
| 9. |
VOE11127138
|
[1] |
Oil pipe
|
|
| 10. |
VOE13947281
|
[2] |
Gasket
|
|
| 11. |
VOE7048634
|
[1] |
Hollow screw
|
|
| 12. |
VOE942400
|
[2] |
Clamp
|
|
| 13. |
VOE13942336
|
[2] |
Spring washer
|
|
| 14. |
VOE955534
|
[2] |
Hexagon screw
|
|
| 15. |
VOE952623
|
[1] |
Clamp
|
|
| 16. |
VOE842350
|
[1] |
Spacer sleeve
|
|
| 17. |
VOE956095
|
[1] |
Cross recessed screw
|
|
| 18. |
VOE11031824
|
[1] |
Oil return pipe
|
|
| 19. |
VOE11031827
|
[1] |
Nipple
|
|
| 20. |
VOE942703
|
[1] |
Gasket
|
|
| 21. |
VOE942007
|
[1] |
Hollow screw
|
|
| 22. |
VOE942703
|
[1] |
Gasket
|
|
| 22A. |
VOE13947624
|
[1] |
Plane gasket
|
|
| 23. |
VOE60113509
|
[1] |
Hollow screw
|
|
| 24. |
VOE13969011
|
[2] |
Gasket
|
|
| 25. |
VOE954386
|
[1] |
Elbow nipple
|
|
| 26. |
VOE11031746
|
[1] |
Tube
|
|
| 27. |
VOE954365
|
[1] |
Olive
|
|
| 28. |
VOE954357
|
[1] |
Nut
|
|
| 29. |
VOE13947282
|
[2] |
Gasket
|
|
| 30. |
VOE13947975
|
[1] |
Hollow screw
|
|
| 31. |
VOE7018368
|
[1] |
Clamp
|
|
| 32. |
VOE930840
|
[1] |
Plain washer
|
|
| 33. |
|
[1] |
Screw
|
|
