神钢零件查询(6D15-T) - MITSUBISHI DIESEL ENGINE - K909 II & K909LC II EXCAVATORS (1/87-12/06) (02-006) - GOVERNOR(INNER PARTS) Kobelco
广数供应链运营团队, 14 02月, 2025，浏览：
738 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 6D160WT-KS12 | [1] | GOVERNOR,INNER PARTS(M4) | |
| 1-336. | VAME723045 | [1] | GOVERNOR ASSY RFD TYPE | |
| 1. | VAME704500 | [1] | H0USING,GOV | |
| 4. | VAME722139 | [1] | LEVER,STOP | |
| 6. | VANE704502 | [1] | ADAPTER | |
| 7. | VAME705224 | [1] | BOLT | KOBBOLT Superseded by part number: VA0200181840 |
| 9. | VAME704503 | [1] | PLATE | KOBPLATE |
| 10. | VAME705284 | [5] | BOLT | KOBBOLT Superseded by part number: VA0290106810 |
| 11. | VAME705226 | [1] | BOLT | KOBBOLT Superseded by part number: VA0201061640 |
| 12. | VAME716175 | [1] | BOLT | |
| 13. | VAME705227 | [1] | NUT,LOCK | |
| 14. | VAME704505 | [1] | SCREWDRIVER | KOBNUT,LOCK |
| 14B. | VAME704977 | [1] | NUT,LOCK | |
| 35. | VAME723504 | [1] | COVER,GOV | |
| 35B. | VAME704507 | [1] | BUSHING | |
| 35C. | VAME705228 | [1] | OIL SEAL | |
| 38. | VAME704413 | [1] | SCREW | |
| 39. | VAME705229 | [2] | NUT | |
| 47. | VAME704509 | [2] | PLUG | |
| 48. | VAME704510 | [1] | BOLT | |
| 49. | VAME704511 | [1] | NUT | |
| 50. | VAME704512 | [1] | SCREW | |
| 51. | VAME705230 | [5] | BOLT | |
| 52. | VAME705231 | [1] | BOLT | |
| 52B. | VAME717943 | [1] | BOLT | |
| 53. | VAME716097 | [1] | LIMIT SWITCH | KOBBOLT |
| 54. | VAME717712 | [1] | SPRING WASHER | KOBWASHER,SPG |
| 65. | VAME716097 | [1] | LIMIT SWITCH | KOBLIMITER |
| 80. | VAME704515 | [1] | COVER | |
| 82. | VAME705232 | [1] | BOLT | KOBBOLT Superseded by part number: VA0290206210 |
| 83. | VAME717714 | [1] | BOLT | KOBBOLT Superseded by part number: VA0200061640 |
| 84. | VAME705232 | [1] | BOLT | KOBBOLT Superseded by part number: VA0290206210 |
| 86. | VAME717714 | [1] | BOLT | KOBBOLT Superseded by part number: VA0200061640 |
| 100. | VAME704516 | [1] | FLYWEIGHT ASSY | |
| 101. | VAME705233 | [1] | KEY | KOBKEY,WOODRUFF Superseded by part number: VA0258031610 |
| 102. | VAME705234 | [1] | WASHER | KOBWASHER,SPG |
| 103. | VAME705235 | [1] | HUT | |
| 117. | VAME704517 | [1] | SLEEVE | KOBSLEEVE |
| 117. | VAME705236 | [1] | SHIM | KOBSHIM,T=0.2 |
| 117. | VAME705237 | [1] | SHIM | KOBSHIM,T = 0.3 |
| 117. | VAME705238 | [1] | SHIM | KOBSHIM,T = 0.1 |
| 117. | VAME705239 | [1] | SHIM | KOBSHIM,T=1.0 |
| 117. | VAME717875 | [1] | SHIM | KOBSHIM,T = 0.5 |
| 117. | VAME717876 | [1] | SHIM | KOBSHIM,T = l. 5 |
| 130. | VAME704573 | [1] | SPRING,GOV | |
| 132. | VAME7I7321 | [1] | SPRING.START | |
| 134. | VAME722143 | [1] | ADAPTER | |
| 135. | VAME704906 | [1] | CAPSULE,SPG | |
| 136. | VAME705341 | [1] | NUT | |
| 137. | VAME705218 | [2] | GASKET | KOBGASKET Superseded by part number: VA0265121540, 77270060 |
| 138. | VAME704540 | [1] | NUT | KOBNUT,CAP Superseded by part number: VA1541591200 |
| 140. | VAME722847 | [1] | CAPSULE,SPG | |
| 141. | VAME705240 | [1] | NUT | |
| 150. | VAME704521 | [1] | LEVER.SWIVEL | |
| 151. | VAME704522 | [2] | RUSHING | |
| 152. | VAME705241 | [2] | O-RING | |
| 153. | VAME704523 | [2] | RING,SNAP | |
| 154. | VAME722299 | [1] | OILSEAL | |
| 155. | VAME705243 | [1] | SHIM | |
| 156. | VAME705244 | [1] | SHIM,T = 0.1 | |
| 156. | VAME705245 | [1] | SHIM,T = 0.2 | |
| 156. | VAME705246 | [1] | SHIM,T = 0.3 | |
| 157. | VAME705247 | [1] | PLUG | |
| 159. | VAME705248 | [1] | KEY | KOBKEY,WOODRUFF Superseded by part number: VA0258031310 |
| 160. | VAME704524 | [1] | COLLAR | |
| 161. | VAME704525 | [1] | WASHER | |
| 170. | VAME704526 | [1] | GUIDE LEVER ASSY | |
| 173. | VAME705249 | [1] | SNAP RING | KOBRING,SNAP |
| 174. | VAME794527 | [1] | LINK | |
| 171. | VAME704416 | [1] | PIN | |
| 160. | VAME705249 | [1] | SNAP RING | KOBRING,SNAP |
| 181. | VAME704529 | [1] | LEVER,TENSION | |
| 182. | VAME704530 | [1] | PIN,TENSION LEVER | |
| 103. | VAME704531 | [1] | COLLAR | |
| 190. | VAME704643 | [1] | LEVER | |
| 191. | VAME704533 | [1] | LEVER,GOV | |
| 192. | VAME705250 | [1] | BOLT | |
| 203. | VAME705252 | [1] | SHIM,T=0.95 | |
| 203. | VAME705253 | [1] | SHIM,T=0.20 | |
| 203. | VAME705254 | [1] | SHIM,T=0.25 | |
| 203. | VAME705255 | [1] | SHIM,T=0.30 | |
| 203. | VAME705256 | [1] | SHIM,T=0.35 | |
| 203. | VAME705257 | [1] | SHIM,T=0.40 | |
| 203. | VAME705258 | [1] | SHIM,T=0.50 | |
| 203. | VAME716756 | [1] | SHIM,T=0.7 | |
| 203. | VAME716757 | [1] | SHIM,T = 0.9 | |
| 203. | VAME716758 | [1] | SHIM,T=0.8 | |
| 205. | VAME722852 | [1] | SHAFT | |
| 207. | VAME704538 | [1] | LEVER | |
| 211. | VAME705259 | [1] | RING,SNAP | |
| 220. | VAME704583 | [1] | CAPSULE,SPG | |
| 221. | VAME705341 | [1] | NUT | |
| 222. | VAME705218 | [2] | GASKET | KOBGASKET Superseded by part number: VA0265121540, 77270060 |
| 223. | VAME704540 | [1] | NUT | KOBNUT,CAP Superseded by part number: VA1541591200 |
| 235. | VAME704541 | [1] | IMPELLER | |
| 236. | VAME704542 | [1] | GASKET | KOBGASKET Superseded by part number: VA1543507700 |
| 237. | VAME704543 | [1] | GASKET | |
| 238. | VAME705261 | [1] | O-RING | |
| 248. | VAME722142 | [1] | BRACKET | |
| 249. | VAME716727 | [1] | BOLT | |
| 251. | VAME705378 | [1] | WASHER,SPG | |
| 336. | VAME705276 | [1] | PACKING | KOBGASKET Superseded by part number: VA0293316030, 77270063 |
