斗山零件查询OIL COOLER PIPING(3) DX220A / DX225LCA Doosan parts catalog online
广数供应链运营团队, 14 02月, 2025，浏览：
841 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| -. |
K1039406A
|
[-] |
OIL COOLER PIPING
|
|
| -. |
420212-00225
|
[-] |
|
|
| -. |
420212-13915
|
[-] |
|
|
| 14. |
2181-1126D6
|
[1] |
ADAPTER
|
|
| 16. |
DS2213167
|
[1] |
ADAPTER
|
|
| 19. |
2181-1702D73
|
[1] |
ELBOW
|
|
| 2. |
140-02009A
|
[1] |
PIPE
|
|
| 22. |
S2215366
|
[4] |
BOLT
|
|
| 31. |
S8000181
|
[3] |
O-RING
|
|
| 33. |
S8000291
|
[1] |
O-RING
|
|
| 34. |
2180-1026D24
|
[1] |
O-RING
|
DS2856005
|
| 34. |
DS2856005
|
[1] |
O-RING
|
|
| 39. |
2184-1036D293
|
[1] |
HOSE PF1/2-600L
|
|
| 40. |
DS20551024
|
[1] |
HOSE
|
|
| 41. |
DS2055976
|
[1] |
HOSE
|
|
| 61. |
2181-1951D5
|
[1] |
TEE
|
|
