凯斯零件查询(8610) - CASE IH BALE PROCESSOR (1/86-12/00) (9-32) - SMALL BALE DRIVER KIT ASSEMBLY, HK50552 SMALL BALE DRIVER KIT COMPLETE Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
973 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| . . |
HK50552
|
[1] |
SMALL BALE DRIVER KIT COMPLETE
|
|
| 1. |
700108971
|
[1] |
SUPPORT
|
HFI
- driver, left
|
| 2. |
700108972
|
[1] |
DIVIDER ASSY.
|
HFI
DRIVER - bale
|
| 3. |
700108970
|
[1] |
SUPPORT
|
HFI
- driver, right
|
| 4. |
433-620
|
[2] |
CARRIAGE BOLT,Sq Nk, 3/8" - 16 x 1 1/4", Gr 5
|
CAS
BOLT, CARRIAGE, Short NK, 3/8"-16 x 1 1/4", G5 Superseded by part number: 86508773
|
| 5. |
496-11041
|
[2] |
WASHER,13/32" x 13/16" x .065", HDN
|
CAS
3/8 HARDENED PLAIN WASHER Superseded by part number: 86632588
|
| 6. |
492-11038
|
[2] |
LOCK WASHER,3/8"
|
CAS
Superseded by part number: 80680, 72187249
|
| 7. |
425-106
|
[2] |
NUT,3/8"-16, Cl 5
|
CAS
Superseded by part number: 9628503
|
| 8. |
413-820
|
[2] |
BOLT,Hex, 1/2" - 13 x 1-1/4", Gr 5
|
CAS
Superseded by part number: 72187215, 87670
|
| 9. |
80679
|
[2] |
LOCK WASHER,1/20.507 CST ZND
|
NH
WASHER, LOCK, 1/2"
|
| 10. |
425-108
|
[2] |
NUT,1/2" - 13, Gr 5
|
CAS
NUT, , Hex 1/2"-13, G5 Superseded by part number: 280431
|
