纽荷兰零件查询(F5HFL413B A002) - ENGINE 5801438206 - 84393712 (55.414.01) - DIAGNOSTIC SENSOR (504388686) New Holland Constructuion
广数供应链运营团队, 14 02月, 2025，浏览：
688 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 2852157 | [1] | SENSOR | TORWater Superseded by part number: 504025599 |
| 2. | 2852889 | [1] | PRESSURE SWITCH | TOR Superseded by part number: 504084983 |
| 3. | 7177194 | [1] | | PLUG |
| 4. | 4897242 | [1] | SENSOR | TOR |
| 5. | 504065023 | [3] | SCREW,M6 x 16mm, Cl 8.8 | TOR |
| 6. | 504048261 | [1] | SENSOR | TOR |
| 7. | 42546366 | [1] | O-RING | TOR |
| 8. | 504387528 | [1] | RETAINER | TOR |
| 9. | 504381064 | [1] | SENSOR | TOR |
| 10. | 5801382522 | [1] | SENSOR | TOR |
| 11. | 5801382524 | [1] | RETAINER | TORM6 x 16 |
| 12. | 504369148 | [1] | SENSOR | TOR |
| 13. | 16511214 | [1] | M6X12 mm | HYD CONNECTOR,M12 x 1.5 x 30mm |
| 14. | 5801495064 | [2] | SEAL | TOR |
| 15. | 504387525 | [1] | TUBE | TOR |
| 16. | 2852820 | [1] | O-RING,0.07" Thk x 0.676" ID, 17, Cl 7, 75 Duro | TOR Superseded by part number: 17278481 |
