纽荷兰零件查询(F5HFL463A F001) - ENGINE 5801390425 - 84315306 (47374655) (10/13-) (10.101.AA) - CYLINDER New Holland Constructuion
广数供应链运营团队, 14 02月, 2025，浏览：
757 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 504389002 | [1] | CYLINDER HEAD | TOR |
| 1. | 47508144R | [1] | REMAN-CYLINDER HEAD | TOR |
| 1. | 47508144C | [1] | CORE-CYLINDER HEAD | TORReturn Number |
| 2. | 504162949 | [4] | VALVE SEAT | TOR |
| 3. | 4749397 | [8] | VALVE GUIDE,Std | TOR |
| 3. | 4749398 | [8] | VALVE GUIDE,+0.10 | TOR |
| 3. | 4749399 | [8] | VALVE GUIDE,+0.2 | TOR |
| 4. | 99435557 | [1] | DOWEL,8.50mm Dia | TOR Superseded by part number: 2852481 |
| 5. | 504254094 | [4] | VALVE SEAT | TOR |
| 6. | 16988301 | [8] | PLUG | TOR |
| 7. | 504081521 | [6] | BOLT,M15 x 1.5 x 193mm | TOR |
| 8. | 504081533 | [4] | BOLT,M12 x 1.5 x 165mm | TOR |
| 9. | 5801450757 | [1] | CYLINDER HEAD GASKET,0.80mm Thk | TOR |
| 10. | 5801475385 | [8] | STUD,M8 x 1.25 | TOR |
| 11. | 16990970 | [1] | PLUG,Lock, 30mm Dia | TOR |
| 12. | 16990670 | [4] | PLUG,Lock, 22mm Dia | BRE |
