神钢零件查询(6D15-T) - MITSUBISHI DIESEL ENGINE - K909LC & MD240BLC (1/87-12/06) (01-021) - CAMSHAFT Kobelco
广数供应链运营团队, 14 02月, 2025，浏览：
377 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | VAME030999 | [1] | CAMSHAFT | KOB |
| 2. | VAMH037137 | [1] | PLUG | KOBPLUG |
| 3. | VAMF660068 | [1] | PACKING | KOBGASKET 20 Superseded by part number: VAF420220000 |
| 4. | VAMS476135 | [1] | KEY | KOBKEY, WOODRUFF 5 X 19 Superseded by part number: 132499A1 |
| 5. | VAME031768 | [1] | THRUST PLATE | KOB Superseded by part number: VAME071319 |
| 6. | VAMF140223 | [2] | BOLT | KOBBOLT, FLANGE, 8 X 16 |
