纽荷兰零件查询(F5HFL463A F001) - ENGINE 5801390425 - 84315306 (47374655) (10/13-) (10.218.AF) - FUEL INJECTOR New Holland Constructuion
广数供应链运营团队, 14 02月, 2025，浏览：
394 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 5801569141 | [4] | INJECTOR, EMISSIONS | TORASSY, Incl 2, 3, 7, 8 |
| 2. | NSS | [4] | NOT SERVICED SEPARATELY | CONInjector, Incl in 1 |
| 3. | 4899689 | [4] | SEALING WASHER,7mm ID x 15mm OD x 1.5mm Thk | TOR |
| 4. | 504378841 | [4] | BRACKET | TOR |
| 5. | 5801473742 | [4] | STUD | TOR |
| 6. | 500353601 | [4] | WASHER | TOR |
| 7. | 17044735 | [4] | NUT,Hex, M8 | TORFlg, M8 x 1.25 |
