纽荷兰零件查询(F5HFL463A F001) - ENGINE 5801390425 - 84315306 (47374655) (10/13-) (10.501.AC) - EXAUST SYSTEM, EGR, PIPE New Holland Constructuion
广数供应链运营团队, 14 02月, 2025，浏览：
184 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 5801385612 | [1] | TUBE | TORASSY, Incl 2 - 7 |
| 2. | 18137825 | [2] | BOLT,Hex, M6 x 16mm | TOR |
| 3. | NSS | [1] | NOT SERVICED SEPARATELY | CONPipe, Incl in 1 |
| 4. | 4798845 | [3] | BOLT,M8 x 1.25 x 16.50mm | TOR |
| 5. | 18186570 | [8] | COLLAR CLAMP | TOR |
| 6. | 5135738 | [3] | O-RING,0.103" Thk x 0.674" ID, -115, 80 Duro | TTF |
| 7. | 17289181 | [1] | WASHER, SEALING | TOR |
| 8. | 5801623218 | [1] | HOSE | TOR |
| 9. | 5801459454 | [1] | PIPE | TORASSY, Incl 6, 10 |
