| 1. |
276697A2
|
[1] |
FRAME
|
CAS
ASSY.
|
| 2. |
277984A1
|
[1] |
PLUG
|
CAS
50 x 25 mm
|
| 3. |
276561A1
|
[1] |
PLUG
|
CAS
60 x 60 mm
|
| 4. |
276716A1
|
[1] |
COVER
|
CAS
top
|
| 5. |
892-11012
|
[4] |
LOCK WASHER,M12
|
CAS
Superseded by part number: 412123
|
| 6. |
614-12030
|
[4] |
BOLT,Hex, M12 x 1.75 x 30mm, Cl 8.8, Full Thd
|
IH
Superseded by part number: 9706687
|
| 7. |
278130A1
|
[2] |
BEARING HOUSING,35 mm ID x 46 mm
|
CAS
HOUSING ASSY., Includes: 7A
|
| 7A. |
NSS
|
[1] |
NOT SOLD SEPARAT
|
CON
BEARING ball, Not Illustrated
|
| 8. |
219-14
|
[5] |
LUBE NIPPLE,1/4" NPTF
|
CAS
|
| 9. |
614-16035
|
[4] |
BOLT,Hex, M16 x 2 x 35mm, Cl 8.8, Full Thd
|
CAS
Superseded by part number: 86529976
|
| 10. |
895-11016
|
[1] |
WASHER,17.5mm ID x 30mm OD x 3mm Thk
|
CAS
Superseded by part number: 80299
|
| 11. |
277987A1
|
[1] |
PLUG
|
CAS
17.5 mm
|
| 13. |
REF
|
[1] |
INSTRUCTION
|
NH
BRACKET ASSY., See Figure: 2-52
|
| 14. |
614-6016
|
[1] |
BOLT,Hex, M6 x 1 x 16mm, Cl 8.8, Full Thd
|
CAS
Superseded by part number: 86508568
|
| 17. |
276698A1
|
[2] |
ROLLER
|
CAS
|
| 18. |
614-16025
|
[2] |
BOLT,Hex, M16 x 2 x 25mm, Cl 8.8, Full Thd
|
CAS
Bolt, Hex, M16 x 25, 8.8, Full Thd Superseded by part number: 374888
|
| 19. |
282133A1
|
[4] |
SPECIAL WASHER
|
CAS
|
| 20. |
276700A1
|
[5] |
BELT
|
CAS
|
| 21. |
277207A1
|
[1] |
TUBE,50 mm ID, 60.3 mm OD, 690 mm Length
|
CAS
roller
|
| 22. |
277208A1
|
[2] |
BUSHING
|
CAS
|
| 23. |
277209A1
|
[1] |
SHAFT
|
CAS
|
| 24. |
864-12040
|
[2] |
HEX SOC SCREW,M12 x 40mm, Cl 8.8
|
CAS
M12 x 40 Superseded by part number: 14422221
|
| 25. |
277211A1
|
[1] |
BRACKET
|
CAS
left
|
| 25. |
277212A1
|
[1] |
BRACKET
|
CAS
right
|
| 26. |
814-16100
|
[4] |
BOLT,Hex, M16 x 2 x 100mm, Cl 8.8
|
CAS
Superseded by part number: 374889
|
| 28. |
832-10416
|
[4] |
NUT,M16 x 2, Cl 8
|
CAS
Superseded by part number: 412066
|
