凯斯零件查询(8640) - CASE IH BALE WRAPPER (1/97-12/97) (2-12) - TOP FRAME, LOCKING SYSTEM, 8630, 8640, 8650, ELECTRONIC CONTROL, 8640, 8650, CABLE CONTROL Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
261 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| . . |
313640A1
|
[1] |
KIT
|
CAS
consists of: 1-3, 4, 5, 6-11,13 round bale #8630
|
| . . |
313641A1
|
[1] |
KIT
|
CAS
consists of: 1, 2, 3A, 4A, 5A, 6-11, 13 #8640
|
| . . |
319122A1
|
[1] |
KIT
|
CAS
consists of: 1-3, 4,5, 6-11, 13, 319083A1, 319084A1 round/rectangular bale #8630
|
| . . |
319121A1
|
[1] |
KIT
|
CAS
consists of: 1-3A 4A, 5A, 6-11, 13, 319083A1, 319084A1 #8650
|
| 1. |
313095A1
|
[1] |
CYLINDER
|
CAS
|
| 1A. |
313096A1
|
[1] |
KIT
|
CAS
repai, Not Illustrated
|
| 2. |
313094A1
|
[1] |
BRACKET
|
CAS
#8630
|
| 3. |
814-12090
|
[4] |
BOLT,Hex, M12 x 1.75 x 90mm, Cl 8.8
|
CAS
Superseded by part number: 86508581
|
| 4. |
895-11012
|
[8] |
WASHER,13.5mm ID x 24mm OD x 2.5mm Thk
|
CAS
|
| 5. |
832-10412
|
[4] |
NUT,M12 x 1.75, Cl 8
|
CAS
Superseded by part number: 412126, 87780366
|
| 6. |
313098A1
|
[1] |
HOSE
|
CAS
ASSY., 795 mm
|
| 7. |
313100A1
|
[2] |
TEE
|
CAS
|
| 8. |
277034A1
|
[1] |
ADAPTER
|
CAS
|
| 9. |
313104A1
|
[1] |
VALVE
|
CAS
check
|
| 10. |
277035A1
|
[2] |
SEAL
|
IH
|
| 11. |
313105A1
|
[1] |
ELBOW
|
CAS
|
| 12. |
277630A1
|
[1] |
HOSE
|
CAS
ASSY., 1320 mm #8630
|
| 12. |
277894A1
|
[1] |
HOSE
|
CAS
ASSY., 2000 mm #8640, 8650
|
| 13. |
314017A1
|
[1] |
HOSE
|
CAS
ASSY., 2760 mm
|
| 14. |
REF
|
[1] |
INSTRUCTION
|
NH
VALVE control, See Figure: 2-34, 36 and 40
|
