凯斯零件查询(8640) - CASE IH BALE WRAPPER (1/97-12/97) (2-36) - HYDRAULIC SYSTEM, 8640, 8650, ELECTRONIC CONTROL Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
614 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
283851A1
|
[1] |
VALVE
|
CAS
control, Includes: 2 and 24
|
| 2. |
277873A1
|
[3] |
CONTROL LEVER
|
CAS
|
| 3. |
277033A1
|
[2] |
HOSE
|
CAS
ASSY., 2000 mm
|
| 4. |
277034A1
|
[1] |
ADAPTER
|
CAS
|
| 5. |
277035A1
|
[1] |
SEAL
|
IH
|
| 6. |
277620A1
|
[1] |
MANIFOLD
|
CAS
ASSY.
|
| 7. |
277037A1
|
[4] |
SEAL
|
CAS
1/2 in BSP
|
| 8. |
277036A1
|
[2] |
COUPLING, BREAK AWAY
|
CAS
|
| 8A. |
291354A1
|
[2] |
DUST CAP
|
CAS
Not Illustrated
|
| 9. |
277624A1
|
[2] |
HOSE
|
CAS
ASSY., 750 mm
|
| 10. |
277894A2
|
[1] |
HOSE
|
CAS
ASSY., 2100 mm hydraulic motor See Figure: 2-24
|
| 12. |
277623A1
|
[1] |
HOSE
|
CAS
ASSY., 520 mm tilt See Figure: 2-28
|
| 13. |
277888A1
|
[4] |
HOSE
|
CAS
ASSY., 2180 mm position See Figure: 2-30
|
| 15. |
814-8070
|
[3] |
BOLT,Hex, M8 x 1.25 x 70mm, Cl 8.8
|
CAS
Superseded by part number: 7120024
|
| 16. |
895-11008
|
[4] |
WASHER,9mm ID x 16mm OD x 1.6mm Thk
|
CAS
Superseded by part number: 86624184
|
| 17. |
832-10408
|
[4] |
NUT,M8 x 1.25, Cl 8.8
|
CAS
Superseded by part number: 86528579
|
| 18. |
283852A1
|
[1] |
HOSE
|
CAS
ASSY., 1750 mm hydraulic motor See Figure: 2-24
|
| 19. |
277626A1
|
[2] |
HOSE
|
CAS
ASSY., 2000 mm film tensioner See Figures: 2-34, 64 and 72
|
| 20. |
277893A1
|
[2] |
HOSE
|
CAS
ASSY., 350 mm
|
| 21. |
277171A1
|
[2] |
ADAPTER
|
CAS
|
| 22. |
277629A1
|
[1] |
VALVE
|
CAS
priority
|
| 23. |
277933A1
|
[2] |
HOSE
|
CAS
ASSY., 2450 mm valve, diverter #8650 See Figure: 2-44
|
| 24. |
279793A1
|
[3] |
HOUSING
|
CAS
|
| 25. |
315416A1
|
[1] |
VALVE
|
CAS
relief
|
| 25. |
315565A1
|
[1] |
PLUG
|
CAS
If Used
|
| 26. |
315566A1
|
[1] |
PLUG
|
CAS
|
| 27. |
315415A1
|
[6] |
SOLENOID
|
CAS
|
| 28. |
277889A2
|
[1] |
HOSE
|
CAS
ASSY., 2870 mm Lift #8640 See Figure: 2-42
|
| 29. |
277891A2
|
[1] |
HOSE
|
CAS
ASSY., 3370 mm Lift #8640 See Figure: 2-42
|
