凯斯零件查询(8640) - CASE IH BALE WRAPPER (1/97-12/97) (2-54) - ELECTRICAL COMPONENTS, 8630, 8640, 8650, ELECTRONIC CONTROL Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
245 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
277677A1
|
[1] |
CONTROL
|
CAS
Includes : 1A - 3
|
| 1A. |
302164A1
|
[1] |
SENSOR
|
CAS
ASSY., frame Includes: 1C, Not Illustrated
|
| 1B. |
302165A1
|
[1] |
MAGNET
|
CAS
ASSY., Includes: 1C top frame #8630(1), 8640(2), 8650(2), Not Illustrated
|
| 1C. |
NSS
|
[1] |
NOT SOLD SEPARAT
|
CON
BRACKET, Not Illustrated
|
| 2. |
121414A1
|
[2] |
FUSE,20A, Mini, Yellow
|
CAS
Superseded by part number: 10401190
|
| 4. |
277679A1
|
[1] |
BOX
|
CAS
terminal #8630 Includes: 5 and 6
|
| 4. |
283850A1
|
[1] |
BOX
|
CAS
terminal Includes: 5A and 6 #8640, 8650
|
| 5. |
322764A1
|
[1] |
HARNESS
|
CAS
|
| 5A. |
315417A1
|
[1] |
HARNESS
|
|
| 6. |
315418A1
|
[1] |
HARNESS
|
CAS
|
| 7. |
291805A1
|
[1] |
BRACKET
|
CAS
ectronic control, #8650
|
| 8. |
283849A1
|
[1] |
SWITCH
|
CAS
valve, diverter, #8650
|
