纽荷兰零件查询(CV1100) - VIBRATORY ROLLER (7/01-) (02-006-00[01]) - AIR FILTRATION - ENGINE New Holland Constructuion
广数供应链运营团队, 14 02月, 2025，浏览：
435 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 2. | ND031211 | [1] | PLATE | STA |
| 4. | ND050616 | [1] | FLEXIBLE HOSE | STA |
| 5. | ND018264 | [1] | SUPPORT | STA |
| 8. | ND046952 | [2] | NUT | STAM6 |
| 9. | ND046948 | [2] | WASHER | STA |
| 10. | ND048308 | [1] | FLEXIBLE HOSE | STA |
| 12. | ND076198 | [1] | HOSE | STA Superseded by part number: ND115431 |
| 13. | ND031208 | [1] | HALF-COLLAR | STA |
| 17. | ND065524 | [1] | COVER | STA |
| 18. | ND065521 | [2] | HOSE | STA |
| 19. | ND065516 | [1] | AIR CLEANER | STA |
| 20. | ND065534 | [1] | WARNING LIGHT | STA |
| 21. | ND065519 | [2] | CLAMP | STA |
| 22. | ND069508 | [4] | CLAMP | STA |
| 23. | ND069507 | [2] | CLAMP | STA |
| 27. | ND024236 | [2] | BOLT | STAM6 x 40 |
| 28. | ND021302 | [7] | BOLT | STAM10 x 25 |
| 29. | ND021303 | [4] | BOLT | STAM10 x 30 |
| 35. | ND034088 | [7] | NUT | STA |
| 41. | ND035941 | [14] | WASHER | STAID 10 |
| 42. | ND029266 | [15] | WASHER | STAID 10 |
