神钢零件查询(6D15-T) - MITSUBISHI DIESEL ENGINE - K909LC & MD240BLC (1/87-12/06) (08-004) - LINER & PISTON KIT Kobelco
广数供应链运营团队, 14 02月, 2025，浏览：
363 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1-8. | VAME999943 | [3] | KIT | KOBLINER & PISTON 2 CYL, 6D15, M2 ONLY |
| . . | VAME999944 | [3] | LINER, ENGINE CYLIND | KOB6D15T, M3 ONLY |
| . . | VAME999945 | [1] | LINER & PISTON KIT, 1 CYL, SIZE 1 6D16T, M6 ONLY | |
| . . | VAME999946 | [6] | KIT, LINER, PISTON R | KOBSIZE 2, 6D16T, M6 ONLY |
| . . | VAME999947 | [1] | SIZE 3, 6D16T, M6 ONLY | |
| 1. | VAME071064 | [6] | LINER, ENGINE CYLIND | KOBCYL, M2 & M3 ONLY |
| . . | VAME041105 | [1] | LINER, ENGINE CYLIND | KOBLINER, CYL B, SIZE 1, ME041121, M6 ONLY |
| . . | VAME041106 | [6] | LINER, ENGINE CYLIND | KOBLINER, CYL B,B SIZE 2, M6 ONLY |
| . . | VAME041107 | [1] | LINER, ENGINE CYLIND | KOBLINER, CYL B, SIZE 3, M6 ONLY |
| 2. | VAME031610 | [12] | O-RING | KOBM2 & M3 ONLY |
| 3. | VAME071066 | [6] | PACKING | KOBM2 & M3 ONLY |
| 4. | VAME072035 | [6] | PISTON | KOBSTD, M2 ONLY |
| . . | VAME032872 | [6] | PISTON | KOBME032870, M3 ONLY |
| . . | VAME072067 | [6] | ME072065, M6 ONLY | |
| 5. | VAME999444 | [6] | PISTON RING SET, 1 CYL 6D15, 15T, ME032403, M2 & M3 ONLY | PISTON RING SET, 1 CYL 6D15, 15T, ME032403, M2 & M3 ONLY |
| . . | VAME999951 | [6] | 6D16T ME999956 M6 ONLY | |
| 6. | VAME032542 | [6] | PIN | KOBPISTON, M2 ONLY |
| . . | VAME032550 | [6] | PIN | KOBM3 ONLY |
| . . | VAME047021 | [6] | PIN | KOBM6 ONLY |
| 7. | VAME032686 | [12] | SNAP RING | KOB |
| 8. | VAME072126 | [6] | BUSHING | KOBCONN-ROD, M2 & M3 ONLY |
| . . | VAME072128 | [6] | BUSHING | KOBM6 ONLY |
