神钢零件查询(6D15-T) - MITSUBISHI DIESEL ENGINE - K909LC & MD240BLC (1/87-12/06) (03-003) - FUEL INJECTION PUMP GENERAL Kobelco
广数供应链运营团队, 14 02月, 2025，浏览：
167 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1-6. | VAME047493 | [1] | INJECTION PUMP GENEREAL ASSY | |
| 1. | NSS | [1] | NOT SOLD SEPARAT | CONINJECTION PUMP ASSY, AD TYPE, ME722677 |
| 2. | VAME723045 | [1] | GOVERNOR ASSY, RFD TYPE | |
| 3. | VAME704457 | [1] | FEED PUMP | KOBFUEL FEED PUMP ASSY, KE TYPE, ME036703 |
| 4. | VAME047226 | [1] | AUTOMATIC TIMER ASSY, SA TYPE | |
| 5A. | VAME717108 | [1] | SUPPORT | KOB Superseded by part number: VAME036799 |
| 6. | VAME066028 | [1] | CAP, SEAL | |
| 7. | VAME035679 | [1] | CLUTCH DISC | KOBCLUTCH DISK DRIVING Superseded by part number: VAME076553 |
| 8. | VAMH035500 | [1] | O-RING | KOBO-RING 140 |
| 9. | VAME036954 | [1] | STAY, I/P | |
| 10. | VAMF140223 | [4] | BOLT | KOBBOLT, FLANGE, 8 X 16 |
| 14. | VAMF434105 | [4] | NUT | KOBNUT, FLANGE 10 |
| 15. | VAMF434105 | [1] | NUT | KOBNUT, FLANGE 10 |
| 24. | VAME036955 | [1] | SPACER | |
