凯斯零件查询(8650) - CASE IH BALE WRAPPER (1/97-12/97) (2-44) - VALVE, DIVERTER, 8650 Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
918 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
277912A1
|
[1] |
VALVE
|
CAS
priority
|
| 2. |
277034A1
|
[6] |
ADAPTER
|
CAS
|
| 3. |
277035A1
|
[6] |
SEAL
|
IH
|
| 4. |
277174A1
|
[1] |
HOSE
|
CAS
ASSY., 570 mm lift
|
| 5. |
277914A1
|
[1] |
HOSE
|
CAS
ASSY., 1070 mm lift
|
| 6. |
277933A1
|
[2] |
HOSE
|
CAS
ASSY., 2450 mm control valve
|
| 7. |
277181A1
|
[2] |
HOSE
|
CAS
ASSY., 2500 mm bar assembly lift
|
| 8. |
614-6045
|
[1] |
BOLT,Hex, M6 x 1 x 45mm, Cl 8.8, Full Thd
|
CAS
BOLT, M6 x 45; 8.8 Superseded by part number: 15212821
|
