凯斯零件查询(8650) - CASE IH BALE WRAPPER (1/97-12/97) (2-84) - LIFT ARM, 8650 Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
403 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
276937A1
|
[1] |
BAR
|
CAS
ASSY.
|
| 2. |
276941A1
|
[1] |
PIN
|
CAS
|
| 3. |
A30338
|
[4] |
PIN
|
CAS
linch, 1/4 in Superseded by part number: 270184
|
| 4. |
276923A1
|
[2] |
PIN
|
CAS
|
| 5. |
276934A1
|
[1] |
PLUG
|
CAS
100 x 50 mm
|
| 6. |
276935A1
|
[1] |
ARM
|
CAS
order: 319086A1 order also: 1 x 313091A1, 1 x 313842A1 See Figure: 2-30 Superseded by part number: 313091A1, 313842A1, 319086A1
|
| 6. |
319086A1
|
[1] |
ARM ASSY.
|
CAS
Replaces: 276935A1
|
| 7. |
277242A1
|
[1] |
PIN
|
CAS
|
| 8. |
276925A1
|
[1] |
PLATE ASSY.
|
CAS
|
| 9. |
276938A1
|
[1] |
BAR
|
CAS
|
| 10. |
276554A1
|
[2] |
PLUG
|
CAS
60 mm
|
| 11. |
814-12060
|
[8] |
BOLT,Hex, M12 x 1.75 x 60mm, Cl 8.8
|
CAS
Superseded by part number: 9706693
|
| 12. |
832-10412
|
[8] |
NUT,M12 x 1.75, Cl 8
|
CAS
Superseded by part number: 412126, 87780366
|
| 13. |
895-11012
|
[8] |
WASHER,13.5mm ID x 24mm OD x 2.5mm Thk
|
CAS
|
| 14. |
319107A1
|
[2] |
PLATE
|
CAS
BRACKET ASSY. stop
|
| 15. |
276927A1
|
[2] |
PAD, RUBBER
|
IH
|
| 16. |
840-1620
|
[8] |
SCREW,Pan, M6 x 20mm, Cl 4.8
|
CAS
Superseded by part number: 86511830
|
| 19. |
277181A1
|
[2] |
HOSE
|
CAS
ASSY., 2500 mm
|
| 20. |
277185A1
|
[1] |
CLAMP
|
CAS
|
| 21. |
277183A1
|
[2] |
ELBOW
|
CAS
|
| 22. |
276939A1
|
[1] |
CYLINDER
|
CAS
|
| 22A. |
276940A1
|
[1] |
SEAL PACKAGE
|
CAS
Not Illustrated
|
| 23. |
219-14
|
[2] |
LUBE NIPPLE,1/4" NPTF
|
CAS
|
