凯斯零件查询(8650) - CASE IH BALE WRAPPER (1/97-12/97) (2-88) - BALE MAT, 8640, DBG0002025 -, 8650, DBG0004026 - Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
145 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| . . |
313849A1
|
[1] |
KIT
|
CAS
consists of: 1 - 9, 21 and 22 Superseded by part number: 313104A1, 313115A1, 277171A1, 277035A1, 313116A1, 313118A1, 313107A1, 313112A1, 313117A1, 832-10406, 313114A1, 313109A1, 313113A1, 313087A1, 313086A1, 313085A1, 277179A1, 314616A1, 15212821, 313111A1
|
| 1. |
313085A1
|
[1] |
FRAME
|
CAS
ASSY.
|
| 2. |
313086A1
|
[1] |
PIN
|
CAS
255 mm
|
| 3. |
614-6045
|
[3] |
BOLT,Hex, M6 x 1 x 45mm, Cl 8.8, Full Thd
|
CAS
BOLT, M6 x 45; 8.8 Superseded by part number: 15212821
|
| 4. |
832-10406
|
[3] |
NUT,M6 x 1, Cl 8
|
CAS
|
| 5. |
314616A1
|
[1] |
PIN
|
CAS
pivot 770 mm
|
| 6. |
313087A1
|
[1] |
BAR
|
CAS
630 mm
|
| 8. |
313107A1
|
[1] |
CYLINDER
|
CAS
|
| 8A. |
313108A1
|
[1] |
KIT
|
CAS
repair Not Illustrated
|
| 9. |
313118A1
|
[3] |
TEE
|
CAS
|
| 10. |
313109A1
|
[1] |
RUBBER PAD
|
CAS
HOSE ASSY.,168 mm
|
| 11. |
313111A1
|
[1] |
HOSE
|
CAS
ASSY., 2600 mm
|
| 12. |
277179A1
|
[2] |
SEAL
|
CAS
|
| 13. |
313112A1
|
[1] |
ADAPTER
|
CAS
|
| 14. |
313113A1
|
[1] |
VALVE
|
CAS
balance
|
| 15. |
277171A1
|
[2] |
ADAPTER
|
CAS
|
| 16. |
313114A1
|
[1] |
TEE
|
CAS
|
| 17. |
313115A1
|
[1] |
VALVE
|
CAS
relief
|
| 18. |
277035A1
|
[4] |
SEAL
|
IH
|
| 19. |
313116A1
|
[1] |
HOSE
|
CAS
ASSY., 525 mm
|
| 20. |
313100A1
|
[1] |
TEE
|
CAS
|
| 21. |
313117A1
|
[1] |
HOSE
|
CAS
ASSY., 480 mm
|
| 22. |
313104A1
|
[1] |
VALVE
|
CAS
check
|
| 23. |
277624A1
|
[1] |
HOSE
|
CAS
ASSY., 750 mm
|
| 24. |
277034A1
|
[1] |
ADAPTER
|
CAS
|
| 25. |
277893A1
|
[1] |
HOSE
|
CAS
ASSY., 350 mm
|
| 26. |
REF
|
[1] |
INSTRUCTION
|
NH
VALVE control, See Figure: 2-??
|
| 27. |
277620A1
|
[1] |
MANIFOLD
|
CAS
ASSY., See Figure: 2-??
|
| 28. |
276888A1
|
[1] |
CYLINDER
|
CAS
tilt, See Figure: 2-??
|
