纽荷兰零件查询(CV1100) - VIBRATORY ROLLER (7/01-) (12-009-00[01]) - ADAPTING THE DRUM FOR TAMPING COMPACTION New Holland Constructuion
广数供应链运营团队, 14 02月, 2025，浏览：
732 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | ND011370 | [3] | SHELL | STA |
| 2. | ND054304 | [8] | CLAMP | STA |
| 5. | ND048476 | [8] | PLATE | STA |
| 6. | ND031242 | [9] | SCRAPER TOOL | STA |
| 7. | ND031240 | [9] | SCRAPER TOOL | STA |
| 11. | ND021243 | [16] | BOLT | STAM20 x 70 |
| 12. | ND098359 | [18] | SCREW | STA |
| 16. | ND021853 | [36] | NUT | STAM20 |
| 20. | ND035944 | [16] | WASHER | STAID 20 |
| 21. | ND029255 | [36] | WASHER | STAID 21 |
| 25. | NSS | [1] | NOT SERVICED SEPARATELY | CON |
