凯斯零件查询(2400) - INTERNATIONAL HARVESTER ROUND BALER (1/79-12/86) (B-35) - SHIELD ATTACHMENT, EXPORT ONLY, NOT AVAILABLE FOR UNITED STATES Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
490 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
213626C2
|
[1] |
SHIELD
|
IH
twine knife
|
| 3. |
213631C2
|
[1] |
SHIELD
|
IH
rear RH lower roll
|
| 4. |
213630C2
|
[1] |
SHIELD
|
IH
rear LH lower roll
|
| 5. |
213629C2
|
[1] |
SHIELD
|
IH
lower right center roll
|
| . . |
172449
|
[1] |
SCREW,Hex, 5/8" - 18 x 1/2"
|
IH
5/16 x 1/2 h/hd tap Superseded by part number: 276-2488
|
| 7. |
875483R1
|
[2] |
SPACER
|
IH
press roll shield mount
|
| . . |
18784R1
|
[2] |
BOLT,Hex, 3/8"-16 x 2 3/4", G2
|
IH
3/8 x 2-3/4 type 1 Superseded by part number: 88444
|
| . . |
482256R1
|
[2] |
BEARING LOCK NUT,Flg, USR, 3/8"-16
|
IH
3/8-16 znd hex. lock Superseded by part number: 247780
|
| 8. |
453771R1
|
[2] |
PLUG
|
IH
CAP, hub
|
| 9. |
213632C2
|
[1] |
SHIELD
|
IH
press roll shield mount
|
| 10. |
213878C1
|
[1] |
SHIELD
|
IH
ASSY, clutch front
|
| 11. |
214389C1
|
[1] |
SHIELD
|
IH
U-joint
|
