纽荷兰零件查询(CV1500) - VIBRATORY ROLLER (7/01-) (02-005-00[01]) - EXHAUST - ENGINE New Holland Constructuion
广数供应链运营团队, 14 02月, 2025，浏览：
294 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | ND103100 | [1] | MUFFLER | STA |
| 3. | ND028148 | [1] | CLAMP | STA |
| 6. | ND103369 | [1] | CLAMP | STA |
| 7. | ND031214 | [1] | SUPPORT | STA |
| 15. | ND098745 | [1] | CLAMP | STA |
| 16. | ND106299 | [1] | EXTENSION | STA |
| 28. | ND021302 | [7] | BOLT | STAM10 x 25 |
| 30. | ND021206 | [1] | BOLT | STAM10 x 100 |
| 31. | ND021304 | [2] | BOLT | STAM10 x 35 |
| 34. | ND021848 | [1] | NUT | STAM8 Superseded by part number: ND034087 |
| 35. | ND034088 | [7] | NUT | STA |
| 39. | ND029310 | [1] | WASHER | STAID 8,2 |
| 40. | ND029249 | [1] | WASHER | STAID 8,4 |
| 41. | ND035941 | [14] | WASHER | STAID 10 |
| 42. | ND029266 | [15] | WASHER | STAID 10 |
