凯斯零件查询(241) - INTERNATIONAL HARVESTER BIGROLL ROUND BALER (1/74-12/79) (A-38) - RELIEF VALVE ASSEMBLY Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
693 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| . . |
208621C91
|
[1] |
VALVE
|
IH
ASSY, relief, consists of the following service parts
|
| 1. |
213690C1
|
[1] |
VALVE
|
IH
ASSY, relief adjusting screw
|
| 3. |
213691C91
|
[1] |
GASKET KIT
|
IH
PACKAGE, relief valve repair, consists of ref nos 5, 6, 7, 8, 9 and o-ring, less ref no. 4
|
| 4. |
213693C1
|
[1] |
BODY
|
IH
relief
|
| 5. |
213692C1
|
[1] |
GASKET
|
IH
relief Superseded by part number: 34115
|
| 6. |
213694R1
|
[1] |
SPRING, relief
|
|
