| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | ND065087 | [2] | HEADLAMP | STA |
| 2. | ND066894 | [2] | BULB | STA24V 70W |
| 6. | ND026463 | [4] | NUT | STAM10 |
| 9. | ND066052 | [1] | WIRE CONNECTOR | STA |
| 11. | ND066056 | [3] | PIN | STA |
| 13. | ND065927 | [4] | TUBE,99 mm L | STA |
| 15. | ND066054 | [1] | ELEC CONNECTOR | STA |
| 17. | ND065935 | [4] | SHIELD | STA |
| 19. | ND103526 | [1] | ELECTRIC CABLE | STA2600 mm |
| 21. | ND103527 | [1] | FLEXIBLE HOSE | STA400 mm |
