凯斯零件查询(241) - INTERNATIONAL HARVESTER BIGROLL ROUND BALER (1/74-12/79) (A-08) - WHEEL HUBS AND SPINDLES Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
542 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
208444C1
|
[2] |
SPINDLE
|
IH
wheel
|
| . . |
179894
|
[2] |
BOLT,Hex, 1/2" - 13 x 3 1/4", Gr 5
|
IH
Superseded by part number: 88043
|
| . . |
9413956
|
[2] |
LOCK NUT,1/2"-13, GB
|
IH
NUT, 1/2-13 PHC hex. lock Superseded by part number: 231-4138
|
| 2. |
208443C1
|
[2] |
OIL SEAL
|
IH
grease
|
| 3. |
663557R91
|
[2] |
BEARING ASSY,1.625" ID x 2.892" OD x 0.77"
|
IH
BEARING ASSY, wheel inner cone Superseded by part number: 86512015
|
| 4. |
663558R1
|
[2] |
BEARING CUP
|
IH
BEARING, wheel inner cup Superseded by part number: 86512015
|
| 5. |
208441C91
|
[2] |
HUB
|
IH
ASSY, wheel, includes ref. no. 4 and 7
|
| 6. |
403538R2
|
[12] |
WHEEL BOLT,Hex, 9/16" - 18 x 1.21"
|
IH
BOLT, wheel, replaces 364451R1
|
| 7. |
651817R1
|
[2] |
BEARING CUP
|
IH
BEARING, wheel outer cup Superseded by part number: 84356153
|
| 7. |
651817R1GV
|
[2] |
BEARING CUP
|
MKT
Value, Bearing Cup
|
| 8. |
651818R91
|
[2] |
ROLLER BEARING,31.77 mm ID x 16.08 mm
|
IH
BEARING ASSY, wheel outer cone Superseded by part number: 84356153
|
| 9. |
208445C1
|
[2] |
WASHER
|
IH
13/16 x 1-3/4 x 3/16 hard Superseded by part number: 87613290
|
| . . |
472640
|
[2] |
NUT, 3/4-16 znd slt-hex.
|
|
| . . |
20328R1
|
[2] |
COTTER PIN,3/16" x 1 1/2"
|
IH
3/16" x 1 1/2" Superseded by part number: 80754
|
| 10. |
518842R1
|
[2] |
CAP
|
IH
hub
|
