凯斯零件查询(241) - INTERNATIONAL HARVESTER BIGROLL ROUND BALER (1/74-12/79) (A-45) - FLASHING WARNING LIGHT ATTACHMENT Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
273 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
121664C1
|
[2] |
LIGHT
|
IH
ASSY, flashing warning, 12 volt, only serviceable item is
|
| . . |
20010R1
|
[1] |
BULB,C6, #1034A, 12.8V
|
IH
LAMP, type C-6 trade #1076 Superseded by part number: C1TB13465A
|
| 2. |
398976R1
|
[2] |
BRACKET
|
IH
SOCKET, warning light mounting Superseded by part number: 847590
|
| . . |
16888R1
|
[4] |
HARDWARE,Short NK, 5/16"-18 x 1 1/4", G2
|
IH
BOLT, 5/16 x 1-1.4 crg type 1 Superseded by part number: 598804R1
|
| . . |
446363
|
[4] |
WASHER,5/16"
|
IH
.375 x .875 x .604 Superseded by part number: 80664
|
| . . |
120376
|
[4] |
NUT,5/16"-18, G5
|
IH
Superseded by part number: 9635082
|
| 3. |
121662C1
|
[1] |
HARNESS
|
IH
ASSY, rear connector
|
| 4. |
121646C1
|
[1] |
TERMINAL CONNECTOR,Female
|
IH
PLUG, 7 contact w/cable guard
|
| 5. |
121663C1
|
[1] |
HARNESS
|
IH
ASSY, warning light junction
|
| 6. |
358986R1
|
[9] |
CABLE CLIP
|
IH
CLIP, cable harness, short
|
| 7. |
384559R1
|
[2] |
CLIP
|
IH
cable harness, long
|
| 8. |
289862C1
|
[5] |
CABLE TIE,3/16" x 7"
|
IH
STRAP, cable lock Superseded by part number: 529070
|
| 9. |
200549C2
|
[2] |
CLAMP
|
IH
WRAPS, tie
|
| . . |
9426333
|
[1] |
FUSE,15 Amp, Type 3AG
|
IH
AG3, 15 ampere Superseded by part number: 590420
|
