凯斯零件查询(241) - INTERNATIONAL HARVESTER BIGROLL ROUND BALER (1/74-12/79) (A-19) - BELT GUIDE ASSEMBLY PACKAGE Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
362 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| . . |
204819C91
|
[1] |
GUIDE
|
IH
BELT GUIDE ASSY SERVICE PACKAGE, consists of Superseded by part number: 276-14810, 218420C1, 214346C1
|
| 1. |
214346C1
|
[1] |
GUIDE
|
IH
ASSY, belt
|
| 2. |
218420C1
|
[4] |
CHANNEL
|
IH
belt guide
|
| . . |
172451
|
[8] |
SELF-TAP SCREW,Hex Hd, 5/16" x 5/8"
|
IH
SCREW, 5/16 x 5/8 h/hd tap Superseded by part number: 276-14810
|
