纽荷兰零件查询(CV1500) - VIBRATORY ROLLER (7/01-) (04-007-00[01]) - ELECTRICAL CIRCUIT - DIFFERENTIAL LOCK New Holland Constructuion
广数供应链运营团队, 14 02月, 2025，浏览：
436 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | ND031355 | [1] | PLATE | STA |
| 4. | ND090935 | [1] | ECU | STA |
| 6. | ND090938 | [1] | SENSOR | STA |
| 8. | ND090937 | [3] | WIRE CONNECTOR | STAM12 x 1 |
| 11. | ND066656 | [1] | POWER SOCKET | STA |
| 12. | ND065399 | [1] | SWITCH | STA |
| 13. | ND065415 | [1] | LENS | STA |
| 19. | ND024100 | [2] | BOLT | STAM3 x 8 |
| 20. | ND024110 | [4] | BOLT | STAM4 x 12 |
| 21. | ND021302 | [2] | BOLT | STAM10 x 25 |
| 23. | ND026412 | [2] | NUT | STAM3 |
| 24. | ND026416 | [2] | NUT | STAM8 Superseded by part number: ND034087 |
| 26. | ND029305 | [2] | WASHER | STAID 3,1 |
| 27. | ND029306 | [4] | WASHER | STAID 4,1 |
| 28. | ND029310 | [2] | WASHER | STAID -8,2 |
| 29. | ND029311 | [2] | WASHER | STAID 10,2 |
| 31. | ND029249 | [2] | WASHER | STAID 8,4 |
