纽荷兰零件查询(CV1500) - VIBRATORY ROLLER (7/01-) (06-002-00[01]) - HYDRAULIC CIRCUIT, STEERING New Holland Constructuion
广数供应链运营团队, 14 02月, 2025，浏览：
195 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | ND031266 | [1] | BLOCK | STA |
| 2. | ND052872 | [1] | HYD CONNECTOR | STA |
| 3. | ND052876 | [4] | HYD CONNECTOR | STA |
| 4. | ND025192 | [4] | PLATE | STA |
| 7. | ND042815 | [2] | WASHER | STA Superseded by part number: ND029267 |
| 10. | ND075997 | [1] | FLEXIBLE HOSE | STA |
| 11. | ND076077 | [2] | FLEXIBLE HOSE | STA |
| 12. | ND076101 | [1] | FLEXIBLE HOSE | STA |
| 15. | ND090923 | [1] | HYDRAULIC STEERING | STA |
| 16. | ND090924 | [1] | FLANGE | STA |
| 17. | ND067963 | [1] | HYDRAULIC PUMP | STA |
| 18. | ND101582 | [1] | PRESSURE SWITCH | STA |
| 19. | ND062317 | [1] | HYD CONNECTOR | STA |
| 20. | ND062145 | [1] | HYD CONNECTOR | STA |
| 21. | ND062140 | [5] | HYD CONNECTOR | STA |
| 22. | ND062185 | [1] | HYD CONNECTOR | STA |
| 23. | ND062475 | [2] | BANJO BOLT | STA |
| 24. | ND062479 | [1] | BANJO BOLT | STA |
| 25. | ND062304 | [1] | ELBOW | STA |
| 26. | ND062301 | [1] | HYD CONNECTOR | STA |
| 27. | ND062305 | [1] | HYD CONNECTOR | STA |
| 28. | ND062302 | [2] | HYD CONNECTOR | STA |
| 29. | ND062303 | [1] | HYD CONNECTOR | STA |
| 30. | ND062306 | [1] | HYD CONNECTOR | STA |
| 32. | ND062394 | [1] | HYD CONNECTOR | STA |
| 34. | ND062013 | [2] | HALF-COLLAR | STA |
| 35. | ND079933 | [1] | O-RING | STA |
| 36. | ND079934 | [1] | O-RING | STA |
| 37. | ND062037 | [6] | SEAL | STA |
| 38. | ND062036 | [2] | SEAL | STA |
| 39. | ND062058 | [6] | NUT | STA |
| 40. | ND062051 | [2] | NUT | STA |
| 41. | ND062319 | [1] | FITTING | STA Superseded by part number: ND112942 |
| 42. | ND062318 | [1] | PLUG | STA |
| 43. | ND061520 | [2] | FLEXIBLE HOSE | STA600mm |
| 44. | ND061521 | [2] | FLEXIBLE HOSE | STA600mm |
| 45. | ND061522 | [2] | HOSE | STA980mm Superseded by part number: 47477201 |
| 46. | ND061523 | [1] | HOSE | STA1050mm Superseded by part number: 47477205 |
| 47. | ND061711 | [1] | FLEXIBLE HOSE | STA1300mm |
| 49. | ND061525 | [1] | HOSE,980.00 mm | STA |
| 51. | ND061707 | [1] | FLEXIBLE HOSE | STA1500mm |
| 53. | ND079806 | [1] | RING | STA100 x 3 |
| 54. | ND064799 | [6] | CLAMP | STA |
| 55. | ND064813 | [1] | CLAMP | STA |
| 56. | ND073365 | [1] | PACKING RING | STA18 x 24 x 1,5 |
| 57. | ND073363 | [4] | O-RING | STA27 x 32 x 2 |
| 58. | ND073356 | [1] | PACKING RING | STA14 x 18 x 1,5 |
| 60. | ND024233 | [12] | BOLT | STAM6 x 28 |
| 61. | ND024234 | [2] | BOLT | STAM6 x 30 |
| 63. | ND024244 | [4] | BOLT | STAM8 x 20 |
| 65. | ND024257 | [3] | BOLT | STAM10 x 20 |
| 67. | ND024260 | [4] | BOLT | STAM10 x 35 |
| 68. | ND021203 | [4] | BOLT,Hex, M10 x 80mm | STAM10 x 80 |
| 70. | ND021215 | [2] | BOLT | STAM12 x 80 |
| 72. | ND029249 | [4] | WASHER | STAID 8,4 |
| 73. | ND035941 | [7] | WASHER | STAID 10 |
| 75. | ND106910 | [10] | STRAP | STA |
