凯斯零件查询(RB454) - CASE IH ROUND BALER (7/07-1/14) (00.00RB206) - MAINTENANCE PARTS, 1.5 M WIDE PICK-UP REEL Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
194 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
86634528
|
[1] |
CAM
|
NH
RH
|
| 2. |
86634545
|
[1] |
CAM
|
NH
LH
|
| 3. |
84350126
|
[4] |
CAM FOLLOWER,1/2" - 20 x 38mm OD x 54.5mm L
|
NH
|
| 4. |
703960
|
[1] |
WASHER
|
NH
1-1/4" OD, Hardened Superseded by part number: 87642988
|
| 5. |
688917
|
[1] |
WASHER
|
NH
1-3/4" OD Superseded by part number: 86634532
|
| 6. |
65319
|
[1] |
WASHER,13.1mm ID x 25.4mm OD x 3.68mm Thk
|
NH
|
| 7. |
88130
|
[4] |
NUT,1/2"-20, GC
|
NH
|
| 8. |
86628669
|
[4] |
ANGLE BAR
|
NH
|
| 9. |
86551419
|
[48] |
FINGER
|
PA
Pick-up Superseded by part number: 86632007
|
| 10. |
614-10030
|
[44] |
BOLT,Hex, M10 x 1.5 x 30mm, Cl 8.8, Full Thd
|
IH
Superseded by part number: 43140
|
| 11. |
9618968
|
[48] |
WASHER,0.41" ID x 0.78" OD x 0.1" Thk
|
NH
Hardened, 13/32"
|
| 12. |
832-46410
|
[1] |
NUT,M10 x 1.5, Cl 8
|
CAS
Superseded by part number: 100037
|
| 13. |
614-10050
|
[4] |
BOLT,Hex, M10 x 1.5 x 50mm, Cl 8.8, Full Thd
|
CAS
Superseded by part number: 120113
|
