神钢零件查询(6D16-T) - MITSUBISHI DIESEL ENGINE - K907 & MD180LC (1/87-12/06) (03-001) - FUEL INJECTION PUMP GENERAL Kobelco
广数供应链运营团队, 14 02月, 2025，浏览：
367 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1-6. | VAME038925 | [1] | INJ. PUMP GE INJECTION PUMP GENERAL ASSY ,FOR M6 ONLY | INJ. PUMP GE INJECTION PUMP GENERAL ASSY ,FOR M6 ONLY |
| 1-6. | VAME070246 | [1] | INJECTION PUMP GENERAL ASSY,FOR M7 ONLY | |
| 1. | NSS | [1] | NOT SOLD SEPARAT | CONINJECTION PUMP ASSY A TYPE,FOR M6 ONLY |
| 2. | VAME032813 | [1] | GOVERNOR ASSY RSV TYPE,FOR M6 ONLY | |
| 2. | NSS | [1] | NOT SOLD SEPARAT | CONFOR M7 ONLY |
| 3. | VAME032814 | [1] | FEED PUMP | KOBFUEL FEED PUMP ASSY KE TYPE,FOR M6 ONLY Superseded by part number: VAME035928 |
| 4. | VA3186081050 | [1] | TIMER ASSY AUTOMATIC TIMER ASSY SCZ TYPE | TIMER ASSY AUTOMATIC TIMER ASSY SCZ TYPE |
| 6. | VAME039698 | [1] | CASE CASE,TIMER | CASE CASE,TIMER |
| 7. | VAME035679 | [1] | CLUTCH DISC | KOBCLUTCH DISK DISK,DRIVING Superseded by part number: VAME076553 |
| 8. | VAMF520421 | [1] | O-RING | KOBO-RING 125 |
| 9. | VAME070149 | [1] | STAY.I/P | |
| 10. | VAMH000713 | [2] | BOLT | KOBBOLT,FLANGE 10X20 |
| 14. | VAMF434105 | [4] | NUT | KOBNUT,FLANGE 10 |
| 15. | VAMF434105 | [1] | NUT | KOBNUT,FLANGE 10 |
| 16. | VA3186090500 | [1] | LEVER,STOP,FOR M6 ONLY | |
| 18. | VAME039298 | [1] | LEVER LEVER.GOV | LEVER LEVER.GOV |
| 19. | VAMF241229 | [2] | BOLT | KOBBOLT,W/WSR 6X25 |
| 20. | VAMH037116 | [1] | FLEXIBLE JOINT | KOBJOINT,SWIVELING 10 |
