现代零件查询R170W-7 BUCKET(0.69M3 SAE HEAPED HEAVY DUTY)EPC Hyundai
广数供应链运营团队, 14 02月, 2025，浏览：
490 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| . |
62N5-30000
|
[1] |
BUCKET ASSY
|
|
| . |
66N5-38000
|
[1] |
BUCKET ASSY
|
|
| 1. |
62N5-30010
|
[1] |
BUCKET WA
|
|
| 1. |
66N5-38010
|
[1] |
BUCKET WA
|
|
| 1-1. |
E161-3017
|
[5] |
ADAPTER-TOOTH
|
|
| 1-1. |
61N6-31320
|
[5] |
ADAPTER-TOOTH
|
|
| 2. |
E161-3027
|
[5] |
POINT-TOOTH
|
|
| 2. |
61N6-31310BG
|
[5] |
POINT-TOOTH
|
|
| k3. |
E161-3035
|
[5] |
PIN-TOOTH
|
|
| 4. |
61EK-11260
|
[1] |
BUSHING
|
|
| 5. |
61EK-31360
|
[1] |
PLATE-COVER
|
|
| 6. |
61EK-31410
|
[5] |
SHIM
|
|
| 7. |
S017-160502
|
[3] |
BOLT-HEX
|
|
| 8. |
S411-160002
|
[3] |
WASHER-SPRING
|
|
| k9. |
61E5-11150
|
[5] |
WASHER-LOCK
|
|
| K. |
E161-3035-S
|
[1] |
TOOTH PIN KIT
|
|
