纽荷兰零件查询(CV1500) - VIBRATORY ROLLER (7/01-) (12-020-03[01]) - CAB - ROOF New Holland Constructuion
广数供应链运营团队, 14 02月, 2025，浏览：
453 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | ND050469 | [1] | GRILLE | STA |
| 2. | ND017873 | [1] | COVER | STA |
| 4. | ND029684 | [1] | PADDING | STA |
| 5. | ND050477 | [1] | PADDING | STA |
| 6. | ND050479 | [1] | PADDING | STA |
| 18. | ND103120 | [1] | SUPPORT | STA |
| 30. | ND029873 | [1] | PLATE | STA |
| 31. | ND029875 | [1] | PLATE | STA |
| 33. | ND053355 | [1] | RING | STA |
| 41. | ND103220 | [1] | SEALING STRIP | STA1200 mm |
| 42. | ND075258 | [1] | FOAM | STA20 x 230 700 |
| 43. | ND075260 | [1] | CAB FILTER | STA10 x 130 595 |
| 60. | ND064337 | [1] | BLANK-OFF PLUG | STA |
| 62. | ND064663 | [1] | PLUG | STA |
| 70. | ND078528 | [1] | HANDLE | STA |
| 71. | ND100095 | [1] | HOSE | STA |
| 73. | ND079506 | [1] | GROMMET | STA7 x 1 |
| 78. | ND065218 | [1] | JET | STA |
| 81. | ND089999 | [1] | RING | STA |
| 84. | ND064537 | [1] | GRILLE | STA |
| 96. | ND021287 | [1] | BOLT | STAM6 x 12 |
| 100. | ND024138 | [1] | BOLT | STAM6 x 25 |
| 110. | ND025017 | [1] | BOLT | STAM4 x 16 |
| 114. | ND021847 | [1] | NUT | STAM6 |
| 120. | ND029248 | [1] | WASHER | STAID 6,4 |
| 121. | ND029247 | [1] | WASHER | STAID 5,3 |
| 123. | ND029309 | [1] | SPRING WASHER | STAID 6,1 |
| 130. | ND069931 | [1] | RIVET | STA4 x 10 |
| 132. | ND100144 | [1] | PLASTIC-RUBBER TUBE | STA |
