| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | ND094514 | [1] | HALF BLADE | STA |
| 2. | ND095126 | [2] | PIN | STA |
| 3. | ND095087 | [1] | SUPPORT | STA |
| 4. | ND095088 | [1] | SUPPORT | STA |
| 5. | ND030285 | [2] | PIN | STA |
| 6. | ND096261 | [2] | TIE-ROD | STA |
| 7. | ND096260 | [2] | GUIDE | STA |
| 11. | ND049635 | [4] | COVER PLATE | STA |
| 12. | ND096253 | [2] | COVER | STA |
| 13. | ND098214 | [10] | INSERT | STA |
| 14. | ND030296 | [1] | WARNING LIGHT | STA |
| 15. | ND098222 | [2] | LIFTING RING | STA |
| 16. | ND098233 | [2] | PIN | STA |
| 17. | ND096259 | [4] | CUTTING EDGE | STA |
| 18. | ND098212 | [4] | PIN | STA |
| 19. | ND098215 | [8] | RING | STA |
| 26. | ND021171 | [2] | BOLT | STAM5 x 40 |
| 27. | ND021293 | [8] | BOLT | STAM8 x 16 |
| 28. | ND023825 | [4] | SCREW | STAM10 x 16 Superseded by part number: ND092562 |
| 29. | ND024271 | [6] | BOLT | STAM12 x 30 |
| 30. | ND021344 | [12] | BOLT | STAM20 x 50 |
| 31. | ND021243 | [4] | BOLT | STAM20 x 70 |
| 32. | ND021246 | [2] | BOLT | STAM20 x 90 |
| 33. | ND021248 | [2] | BOLT | STAM20 x 110 |
| 34. | ND021251 | [5] | BOLT,Hex, M20 x 140mm | STAM20 x 140 |
| 35. | ND021253 | [5] | BOLT | STAM20 x 160 |
| 39. | ND021846 | [2] | NUT | STAM5 |
| 41. | ND021853 | [16] | NUT | STAM20 |
| 45. | ND029308 | [2] | WASHER | STAID 5,1 |
| 46. | ND029247 | [2] | WASHER | STAID 5,3 |
| 47. | ND035940 | [8] | SPRING WASHER | STAID 8 |
| 48. | ND035941 | [4] | WASHER | STAID 10 |
| 49. | ND029311 | [6] | WASHER | STAID 12,2 |
| 50. | ND035944 | [20] | WASHER | STAID 20 |
| 51. | ND029275 | [2] | WASHER | STAID 26 |
| 55. | ND029392 | [2] | COTTER PIN | STA |
| 60. | ND069897 | [4] | SNAP RING | STA |
| 64. | ND070133 | [6] | LUBE NIPPLE,M10 x 1 | STA |
| 65. | ND064758 | [6] | PLUG | STA |
| 75. | ND079922 | [4] | RING | STA |
| 76. | ND079921 | [4] | RING | STA |
| 81. | ND068776 | [2] | BALL BEARING,70mm ID x 105mm OD x 49mm W | STA |
