凯斯零件查询(RB454) - CASE IH ROUND BALER (7/07-1/14) (08.45[2]) - SHIELDS, REAR, NORTH AMERICA, P.I.N. Y7N016414 & AFTER Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
330 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 3. |
86977964
|
[2] |
SUPPORT
|
PA
Superseded by part number: 87022205
|
| 4. |
86643515
|
[2] |
SUPPORT
|
PA
Superseded by part number: 87022204
|
| 5. |
87673587
|
[1] |
SHIELD
|
NH
|
| 6. |
86643221
|
[1] |
DOOR ASSY.
|
NH
|
| 7. |
632732
|
[1] |
LATCH
|
NH
|
| 8. |
86643486
|
[1] |
SUPPORT
|
PA
|
| 12. |
86643485
|
[1] |
SUPPORT
|
PA
|
| 14. |
87673584
|
[1] |
SHIELD
|
NH
|
| 20. |
9804256
|
[2] |
BOLT,Hex, M6 x 1 x 20mm, Full Thd, Cl 8.8
|
NH
|
| 21. |
9804258
|
[36] |
BOLT,Hex, M8 x 1.25 x 20mm, Cl 8.8
|
NH
|
| 22. |
322357
|
[2] |
BELLEVILLE WASHER,M6 Bolt Size x 14mm OD x 1.3mm Thk
|
NH
|
| 23. |
322358
|
[32] |
BELLEVILLE WASHER,M8 Bolt Size x 18mm OD x 1.4mm Thk
|
NH
|
| 24. |
9804276
|
[2] |
FLANGE NUT,Hex, M6 x 1, Cl 8
|
NH
|
| 25. |
9804277
|
[12] |
FLANGE NUT,Hex, M8 x 1.25, Cl 8
|
NH
Superseded by part number: 86505868
|
| 27. |
86610200
|
[24] |
THREADED INSERT,M8 x 1.25
|
NH
|
