凯斯零件查询(RB454) - CASE IH ROUND BALER (7/07-1/14) (11.35) - SAFETY BRAKE, HYDRAULIC Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
185 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
9839028
|
[1] |
HYD CONNECTOR,M18 x 1.5
|
PA
Female
|
| 2. |
87026874
|
[1] |
HOSE,7.92mm ID x 129mm L, SAE 100R1
|
PA
|
| 3. |
395019
|
[1] |
HYD CONNECTOR,M18 x 1.5 ORB x M16 x 1.5 ORB
|
PA
Male
|
| 4. |
84078124
|
[1] |
HYD CONNECTOR,9/16" - 18 JIC x M16 x 1.5
|
ZED
|
| 5. |
9837647
|
[1] |
ELBOW,90 Degree - 9/16" - 18 JIC 37 Degree x 3/8" BSPP
|
PA
Superseded by part number: 89837647
|
| 6. |
249730
|
[1] |
SECURING STRAP
|
NH
1/8" x 8" Superseded by part number: 249730F, 249730F, 263117
|
| 7. |
9837622
|
[1] |
HYD CONNECTOR,9/16" JIC x 3/8" BSPP
|
PA
|
| 8. |
86513014
|
[1] |
TEE,9/16" - 18 JIC x 9/16" - 18 JIC x 9/16" - 18 JIC
|
BHB
|
| 9. |
87019827
|
[1] |
HOSE,0.38" ID x 79.00", SAE 100R1
|
PA
|
| 10. |
84137881
|
[4] |
STRAP,7.6mm W x 760mm L - Black
|
PLO
|
| 11. |
620019
|
[1] |
CLAMP
|
NH
|
| 12. |
515-23159
|
[1] |
CLAMP,5/8", Insul, 3/8" Bolt
|
CAS
Superseded by part number: 86594406
|
| 13. |
844-10040
|
[1] |
BOLT,Hvy Hex, M10 x 40mm, Cl 8.8
|
CAS
Superseded by part number: 9804263, 87778247
|
| 14. |
832-46410
|
[1] |
NUT,M10 x 1.5, Cl 8
|
CAS
Superseded by part number: 100037
|
