| . . | 6D160WT-KS12 | [1] | STARTER INNER PARTS(M0) | |
| . . | 6D152CT-YJ01 | [1] | STARTER INNER PARTS(M0) | |
| 1-25. | VAME037636 | [1] | STARTER MOTOR | KOBSTARTER ASSY 24V-4.5KW(MEC M003T56072) Superseded by part number: VAME077407 |
| 1. | VAME700050 | [1] | SCREW SCREW SET(MEC M414X05171) | SCREW SCREW SET(MEC M414X05171) |
| 2. | VAME700539 | [1] | BRACKET | KOBBRACKET ASST,FR(MEC M641X68371) |
| 2A. | VAME700540 | [1] | BEARING SET | KOBSLEEVE BEARING SET(MEC M410X13671) |
| 4. | VAME700032 | [1] | LEVER | KOBLEVER ASSY(MEC M863C05671) |
| 5. | VAME700033 | [1] | PACKING PACKING(MEC HS76020501) | PACKING PACKING(MEC HS76020501) |
| 6. | VAME700034 | [1] | BRACKET BRACKET ASSY.CTR(MEC M640826171) | BRACKET BRACKET ASSY.CTR(MEC M640826171) |
| 7. | VAME700035 | [1] | SWITCH | KOBSWITCH ASSY(MEC M371X20571) Superseded by part number: VAM371X20672 |
| 9-11. | VAME700037 | [1] | ARMATURE | KOBARMATURE ASSY(M106X29171) Superseded by part number: VAM106X29171 |
| 10. | VAME700038 | [1] | BEARING | KOBBEARING Superseded by part number: 135040A1 |
| 9. | NSS | [1] | NOT SOLD SEPARAT | CONARMATURE |
| 11. | VAME700039 | [1] | BEARING | KOBBEARING (MEC 3930P12370) Superseded by part number: VAS930P28001 |
| 12. | VAME700036 | [1] | BOLT | KOBBOLT SET (MEC 5930P28070) Superseded by part number: VAM901X01771 |
| 14-18. | VAME700040 | [1] | SHAFT | KOBCLUTCH SET SHAFT ASSY (MEC M901X01771) |
| 14-17. | VAME700041 | [1] | GEAR GEAR SET (MEC M231X00604 | GEAR GEAR SET (MEC M231X00604 |
| 14-15. | VAME700044 | [1] | SET OF PINIONS | KOBPINION 5ET(MEC M605X64571) |
| 14. | NSS | [1] | NOT SOLD SEPARAT | CONPINION |
| 15. | VAME700124 | [1] | STOP | KOBSTOPPER SET (MEC M385X03771) Superseded by part number: VAM385X03771 |
| 16. | VAME700043 | [1] | DRIVEN GEAR | KOBGEAR(MEC M231C00601) |
| 17. | VAME700042 | [1] | SHAFT | KOBPINION SHAFT ASSY (MEC M35X73571) |
| 18. | VAME700045 | [1] | COVER SET COVER SET(MEC M212X11571) | COVER SET COVER SET(MEC M212X11571) |
| 20. | VAME700049 | [2] | PACKING PACKING(MEC HS70014501) | PACKING PACKING(MEC HS70014501) |
| 21. | VAME700046 | [1] | YOKE | KOBYOKE ASSY(MEC M800T43171) |
| 22-23. | VAME700939 | [1] | HOLDER, INJECTOR NOZ | KOBBRUSH HOLDER ASSY(MEC M649T07371) Superseded by part number: 135058A1 |
| 23. | NSS | [1] | NOT SOLD SEPARAT | CONHOLDER,BRUSH |
| 22. | VAMD607462 | [4] | SPRING SPRING,BRUSH(MEC H391C02201) | SPRING SPRING,BRUSH(MEC H391C02201) |
| 24. | VAME700048 | [1] | U-BRACKET | KOBBRACKET,RE(MEC M816D00701 Superseded by part number: 135050A1 |
| 25. | VAME700026 | [2] | SEAL RETAINER | KOBRING,RUBBER(MEC M816D00701) Superseded by part number: 135064A1 |
