纽荷兰零件查询(CV2000) - VIBRATORY ROLLER (12-001-00[01]) - CHASSIS New Holland Constructuion
广数供应链运营团队, 14 02月, 2025，浏览：
270 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | ND104763 | [1] | PIN | STA |
| 2. | ND104768 | [1] | LARGE PIN | STAPIN, LARGE |
| 3. | ND030891 | [1] | COVER | STA |
| 4. | ND052500 | [2] | FLEXIBLE HOSE | STA |
| 5. | ND103151 | [1] | DOOR | STA |
| 6. | ND018499 | [1] | SUPPORT | STA |
| 7. | ND031973 | [1] | COVER | STA |
| 8. | ND103152 | [1] | DOOR | STA |
| 9. | ND106207 | [1] | DOOR | STA |
| 10. | ND103146 | [1] | SUPPORT | STA |
| 11. | ND048918 | [1] | PIN | STA |
| 12. | ND048624 | [1] | PLATE | STA |
| 13. | ND049010 | [1] | PIN | STA Superseded by part number: ND118345 |
| 14. | ND048981 | [1] | PIN | STA |
| 15. | ND028524 | [1] | FIXING PLATE | STA |
| 16. | ND104705 | [1] | COVER | STA |
| 17. | ND052503 | [3] | TIE-ROD | STA |
| 18. | ND049548 | [4] | WASHER | STA |
| 19. | ND049782 | [4] | HINGE | STA |
| 22. | ND031350 | [1] | PLATE | STA |
| 24. | ND104753 | [1] | WALL | STA |
| 25. | ND049707 | [4] | COVER PLATE | STA |
| 26. | ND018489 | [1] | COVER | STA |
| 28. | ND104715 | [1] | COVER | STA |
| 29. | ND104714 | [1] | COVER | STA |
| 30. | ND104690 | [2] | HOUSING | STA |
| 34. | ND106214 | [1] | PLATE | STA |
| 35. | ND106241 | [1] | PROFILE | STA |
| 36. | ND106239 | [1] | PLATE | STA |
| 37. | ND106213 | [1] | PROFILE | STA |
| 38. | ND106240 | [1] | PROFILE | STA |
| 39. | ND069432 | [1] | FLOAT | STA |
| 41. | ND051282 | [8] | WASHER | STA |
| 45. | ND090748 | [3] | STEP | STA |
| 46. | ND090769 | [1] | FILLER CAP | STA |
| 47. | ND065647 | [1] | PLUG | STA |
| 49. | ND090802 | [1] | SCREEN | STA |
| 54. | ND024121 | [7] | BOLT | STA |
| 55. | ND021289 | [4] | BOLT | STAM6 x 20 |
| 56. | ND023792 | [1] | BOLT | STA Superseded by part number: ND110229 |
| 58. | ND021285 | [2] | BOLT | STA |
| 59. | ND021293 | [12] | BOLT | STA |
| 60. | ND021286 | [8] | BOLT | STA |
| 61. | ND021294 | [16] | BOLT | STA |
| 63. | ND024702 | [28] | STUD | STA |
| 64. | ND021301 | [24] | BOLT | STA |
| 65. | ND021302 | [8] | BOLT | STA |
| 66. | ND021292 | [3] | BOLT | STA |
| 69. | ND021847 | [7] | NUT | STA |
| 70. | ND021846 | [2] | NUT | STA |
| 71. | ND021848 | [35] | NUT | STA Superseded by part number: ND034087 |
| 72. | ND034088 | [36] | NUT | STA |
| 74. | ND029248 | [4] | WASHER | STA |
| 75. | ND029309 | [4] | SPRING WASHER | STA |
| 76. | ND029308 | [3] | WASHER | STA |
| 77. | ND029247 | [8] | WASHER | STA |
| 78. | ND029310 | [42] | WASHER | STA |
| 79. | ND029249 | [11] | WASHER | STA |
| 80. | ND029311 | [24] | WASHER | STA |
| 81. | ND029250 | [25] | WASHER | STA |
| 85. | ND029262 | [1] | WASHER | STA |
| 88. | ND079227 | [2] | BUMPER | STA |
| 89. | ND079083 | [1] | BUMPER | STA |
| 90. | ND064758 | [4] | PLUG | STA |
| 94. | ND029374 | [1] | COTTER PIN | STA |
| 95. | ND029396 | [1] | COTTER PIN | STA |
| 99. | ND101584 | [1] | TAPE | STA |
| 103. | ND073360 | [2] | PACKING RING | STA |
| 104. | ND106159 | [1] | FRAME | STA |
