纽荷兰零件查询(CV2000) - VIBRATORY ROLLER (12-005-00[01]) - CHASSIS - DRUM New Holland Constructuion
广数供应链运营团队, 14 02月, 2025，浏览：
204 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | ND104656 | [1] | FRAME | STA |
| 2. | ND104727 | [1] | CROSSBAR | STA |
| 6. | ND053434 | [1] | SCREW | STAM10 x 50 |
| 7. | ND048624 | [1] | PLATE | STA |
| 8. | ND118631 | [4] | PLUG | STA |
| 9. | ND104746 | [1] | COVER | STA |
| 12. | ND037213 | [2] | WASHER | STA |
| 15. | ND021301 | [4] | BOLT | STA |
| 16. | ND021264 | [4] | BOLT | STAM20 x 45 |
| 17. | ND021266 | [4] | BOLT | STAM20 x 60 |
| 20. | ND027302 | [1] | NUT | STAM10 |
| 23. | ND029250 | [1] | WASHER | STAID 10,5 |
| 24. | ND035946 | [8] | SPRING WASHER | STA |
