纽荷兰零件查询(CV2000) - VIBRATORY ROLLER (12-011-00[01]) - DRUM FOR TAMPING COMPACTION New Holland Constructuion
广数供应链运营团队, 14 02月, 2025，浏览：
230 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | ND104667 | [1] | DRUM | STA |
| 2. | ND104726 | [2] | BRACKET | STA |
| 3. | ND104723 | [3] | SUPPORT | STA |
| 4. | ND104724 | [3] | BRACKET | STA |
| 5. | ND104658 | [1] | PLATE | STA |
| 6. | ND028235 | [4] | GASKET | STA |
| 7. | ND104699 | [3] | HOLDER | STA |
| 8. | ND104740 | [2] | BRACKET | STA |
| 10. | ND011958 | [1] | COVER | STA |
| 11. | ND010971 | [1] | COVER | STA |
| 12. | ND017263 | [2] | COVER | STA |
| 13. | ND024775 | [1] | RING | STA |
| 14. | ND104693 | [1] | HUB | STA |
| 15. | ND104777 | [4] | WASHER | STA |
| 16. | ND104736 | [2] | SHIM | STA |
| 17. | ND104737 | [4] | SHIM | STA |
| 18. | ND104745 | [4] | SHIM | STA |
| 19. | ND096237 | [2] | WASHER | STA |
| 20. | ND048387 | [8] | SHIM | STA |
| 21. | ND048389 | [8] | SHIM | STA |
| 22. | ND028190 | [1] | COVER | STA |
| 23. | ND108241 | [2] | O-RING | STA |
| 24. | ND108240 | [2] | O-RING | STA |
| 25. | ND108237 | [1] | RING | STA |
| 26. | ND050390 | [1] | RING | STA Superseded by part number: ND108236 |
| 27. | ND050395 | [1] | WASHER | STA |
| 28. | ND054715 | [4] | SCREW | STA |
| 29. | ND104778 | [4] | WASHER | STA |
| 31. | ND104755 | [4] | HYDRAULIC MOTOR | STA |
| 33. | ND069124 | [1] | NUT | STA |
| 32. | ND069050 | [2] | BEARING | STA |
| 35. | ND090010 | [8] | PAD | STA |
| 34. | ND090011 | [12] | SHOCK ABSORBER | STA |
| 37. | ND079929 | [1] | RING | STA |
| 36. | ND079064 | [1] | GASKET | STA |
| 38. | ND065651 | [5] | PLUG | STA |
| 39. | ND064202 | [1] | HYD CONNECTOR | STA Superseded by part number: ND104623 |
| 41. | ND021269 | [12] | BOLT | STA |
| 42. | ND021264 | [4] | BOLT | STA |
| 43. | ND021245 | [18] | BOLT | STA |
| 44. | ND092868 | [32] | BOLT | STA |
| 46. | ND021230 | [24] | BOLT | STA |
| 45. | ND021235 | [16] | BOLT | STA |
| 47. | ND021228 | [24] | BOLT | STA |
| 48. | ND021333 | [28] | BOLT | STA |
| 49. | ND021331 | [24] | BOLT,Hex, M16 x 40mm | STA |
| 51. | ND021211 | [16] | BOLT | STA |
| 50. | ND024290 | [3] | BOLT | STA |
| 52. | ND021313 | [16] | BOLT | STA |
| 53. | ND021310 | [16] | BOLT | STA |
| 54. | ND021302 | [12] | BOLT | STA |
| 55. | ND021296 | [8] | BOLT | STA |
| 56. | ND021295 | [8] | BOLT | STA |
| 60. | ND021854 | [12] | NUT | STA |
| 61. | ND021853 | [18] | NUT | STA |
| 62. | ND021851 | [90] | NUT | STA |
| 63. | ND034086 | [48] | NUT | STA |
| 65. | ND035946 | [12] | SPRING WASHER | STA |
| 66. | ND035944 | [50] | WASHER | STA |
| 67. | ND035943 | [16] | WASHER | STA |
| 68. | ND035941 | [12] | WASHER | STA |
| 69. | ND029269 | [132] | WASHER | STA |
| 71. | ND073353 | [3] | SEAL | STA |
| 72. | ND073348 | [1] | SEAL | STA |
