神钢零件查询(6D16-T) - MITSUBISHI DIESEL ENGINE - K909LC & MD240BLC (1/87-12/06) (01-009) - FLYWHEEL HOUSING P/N ME070243 Kobelco
广数供应链运营团队, 14 02月, 2025，浏览：
300 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1-6. | VAME070243 | [1] | FLYWHEEL HOUSING ASSY | |
| 1. | NSS | [1] | NOT SOLD SEPARAT | CONHOUSING, FLYWHEEL |
| 3. | VAMF407038 | [1] | STUD, FOR STARTER 12 X 45 | |
| 5. | VAME031062 | [1] | POINTER | KOB |
| 6. | VAMF350047 | [1] | SCREW | KOBSCREW, W/WSR 5 X 10 |
| 9. | VAME020359 | [1] | PLUG | KOBDUST Superseded by part number: VAME609555 |
| 9A. | VAME030870 | [1] | CAP | KOBSEALING |
| 10. | VAMF665007 | [1] | SCREW | KOBPLUG 20 |
| . . | VAMF660068 | [1] | PACKING | KOBGASKET 20 Superseded by part number: VAF420220000 |
| 11. | VAMH000723 | [8] | BOLT | KOBBOLT, FLANGE 10 X 70 |
| 12. | VAMH000716 | [5] | BOLT | KOBBOLT, FLANGE 10 X 55 |
| 13. | VAMH000712 | [1] | SCREW | KOBBOLT, FLANGE 10 X 65 |
| 14. | VAMH000709 | [1] | BOLT | KOBBOLT, FLANGE 10 X 50 |
| 16. | VAME034976 | [1] | OIL SEAL | KOB |
| 18. | VA3110702401 | [1] | O-RING | KOBPACKING, RUBBER Superseded by part number: 3110702401 |
| 19. | VAME030857 | [1] | SEAL | KOB |
| 20. | VAMF241251 | [5] | SCREW | KOBBOLT,W/WSR 8 X 16 |
| 24. | VAME071093 | [1] | PLATE, GEAR RE, D=136.5 | PLATE, GEAR RE, D=136.5 |
