凯斯零件查询(RB454) - CASE IH ROUND BALER (7/07-1/14) (13.459) - 2M WIDE PICKUP, OVERRUN CLUTCH, EUROPE & R.O.W. Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
816 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
87555580
|
[1] |
SHAFT
|
NH
Superseded by part number: 87654213
|
| 2. |
86631322
|
[1] |
CLUTCH PLATE
|
NH
Superseded by part number: 87654239
|
| 3. |
87481
|
[1] |
KEY
|
NH
Sq., 1/4" x 2"
|
| 4. |
87026273
|
[1] |
SPROCKET
|
PA
15T, Includes: (2) Ref. 9 Superseded by part number: 87654402
|
| 5. |
100-16137
|
[2] |
SNAP RING,#137. Ext
|
CAS
Superseded by part number: 86000341
|
| 6. |
29840
|
[2] |
SPRING,Compression, 11.91mm OD x 25.4mm L
|
NH
|
| 7. |
29860
|
[2] |
PIN,12.7mm OD x 35mm L
|
NH
|
| 8. |
130357
|
[3] |
WASHER,35.3mm ID x 60.3mm OD x 1.52 Thk
|
NH
|
| 9. |
219-87
|
[1] |
LUBE NIPPLE,1/4" - 28 NPTF
|
CAS
Superseded by part number: 87414
|
