现代零件查询R170W-7 SWING REDUCTION GEAR(TYPE 2, #1809-)EPC Hyundai
广数供应链运营团队, 14 02月, 2025，浏览：
960 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| . |
@
|
[1] |
SWING MOTOR ASSY
|
|
| -2. |
31N6-10180
|
[1] |
SWING REDUCTION GEAR
|
|
| 1. |
XKAQ-00771
|
[1] |
CASING
|
|
| 2. |
XKAQ-00331
|
[1] |
SHAFT-DRIVE
|
|
| 2. |
XKAQ-00780
|
[1] |
SHAFT-DRIVE
|
|
| 3. |
XKAQ-00018
|
[1] |
SPACER
|
|
| 5. |
XKAQ-00026
|
[1] |
BEARING-ROLLER
|
|
| 6. |
XKAQ-00032
|
[1] |
SEAL-OIL
|
|
| 7. |
XKAQ-00029
|
[1] |
BEARING-ROLLER
|
|
| 7. |
XKAQ-00647
|
[1] |
BEARING-ROLLER
|
|
| 8. |
XKAQ-00076
|
[1] |
PLATE-THRUST
|
|
| 9. |
XKAQ-00075
|
[1] |
CARRIER 2
|
|
| 10. |
XKAQ-00074
|
[1] |
RING-STOP
|
|
| 11. |
XKAQ-00284
|
[1] |
GEAR-RING
|
|
| 11. |
XKAQ-00779
|
[1] |
GEAR-RING
|
|
| 12. |
XKAQ-00072
|
[4] |
PIN-KNOCK
|
|
| 13. |
XKAQ-00976
|
[1] |
GEAR-PINION
|
|
| 14. |
XKAQ-00071
|
[6] |
WASHER-THRUST
|
|
| 15. |
XKAQ-00023
|
[3] |
GEAR-PLANET 2
|
|
| 16. |
XKAQ-00070
|
[3] |
PIN 2
|
|
| 17. |
XKAQ-00048
|
[6] |
PIN-SPRING
|
|
| 18. |
XKAQ-00011
|
[1] |
GEAR-SUN 2
|
|
| 19. |
XKAQ-00015
|
[1] |
CARRIER 1
|
|
| 20. |
XKAQ-00057
|
[3] |
PLATE-SIDE 1
|
|
| 21. |
XKAQ-00019
|
[3] |
PIN 1
|
|
| 22. |
XKAQ-00030
|
[3] |
CAGE-NEEDLE
|
|
| N23. |
@
|
[3] |
BUSHING 2
|
|
| 24. |
XKAQ-00025
|
[3] |
GEAR-PLANET 1
|
|
| 25. |
XKAQ-00292
|
[1] |
WASHER-LOCK
|
|
| 26. |
XKAQ-00068
|
[1] |
PLATE-SIDE 3
|
|
| 27. |
XKAQ-00010
|
[1] |
GEAR-SUN 1
|
|
| 29. |
XKAQ-00049
|
[1] |
PLUG
|
|
| 30. |
XKAQ-00066
|
[2] |
PLUG
|
|
| 31. |
XKAQ-00065
|
[12] |
BOLT-SOCKET
|
|
| 34. |
XKAQ-00031
|
[1] |
PLATE-COVER
|
|
| 35. |
XKAQ-00064
|
[8] |
BOLT-HEX
|
|
| 36. |
XKAQ-00043
|
[1] |
PLATE-LOCK
|
|
| 37. |
XKAQ-00042
|
[2] |
BOLT-HEX
|
|
| 38. |
XKAQ-00041
|
[3] |
RING-STOP
|
|
| 39. |
XKAQ-00040
|
[3] |
PLATE-SIDE 2
|
|
| -1. |
@
|
[1] |
SWING MOTOR UNIT
|
|
| N. |
@
|
[AR] |
NOT SUPPLIED PARTS
|
|
