| 1. |
86620532
|
[2] |
STRAP
|
NH
Superseded by part number: 87654727
|
| 2. |
87728772
|
[1] |
LIFT ARM
|
NH
|
| 3. |
86620245
|
[1] |
MOUNTING PARTS
|
NH
Superseded by part number: 87654743, 86620198
|
| 4. |
86620247
|
[1] |
TUBE,60.50 mm OD x 1577.30 mm L
|
NH
|
| 5. |
86634564
|
[1] |
PIN
|
NH
|
| 6. |
219-90
|
[1] |
LUBE NIPPLE,45 Degree Elbow, 1/4" -28 NPTF
|
CAS
Superseded by part number: 87569
|
| 7. |
86620166
|
[1] |
LINK
|
NH
|
| 8. |
86620277
|
[1] |
ARM
|
NH
Superseded by part number: 87654780
|
| 9. |
86620230
|
[1] |
MOUNTING PARTS
|
NH
Superseded by part number: 87655058, 86620198
|
| 10. |
86636652
|
[1] |
SPACER
|
NH
|
| 11. |
90999
|
[1] |
SPACER,25.65mm ID x 50.8mm OD x 15.88mm L
|
NH
|
| 12. |
87024156
|
[1] |
THREADED ROD
|
PA
Crank Handle Superseded by part number: 87024150
|
| 14. |
33781
|
[1] |
KNOB
|
NH
|
| 15. |
86636631
|
[1] |
HUB
|
NH
|
| 17. |
844-10025
|
[4] |
BOLT,Hex, M10 x 25mm, Cl 8.8
|
CAS
Superseded by part number: 9804261
|
| 18. |
413-644
|
[1] |
BOLT,Hex, 3/8" - 16 x 2-3/4", Gr 5
|
CAS
Superseded by part number: 88444
|
| 19. |
844-10030
|
[7] |
BOLT,Hvy Hex, M10 x 30mm, Cl 8.8
|
CAS
Superseded by part number: 9840672
|
| 20. |
811-10030
|
[1] |
CARRIAGE BOLT,Sht Sq Nk, M10 x 1.5 x 30mm, Cl 8.8
|
CAS
Superseded by part number: 86512446
|
| 22. |
235126
|
[2] |
WASHER,10.3mm ID x 38mm OD x 1.7mm Thk
|
NH
Special
|
| 23. |
56867
|
[2] |
WASHER
|
NH
Special, Hardened Superseded by part number: 578092
|
| 24. |
213404
|
[1] |
SPACER,10.3mm ID x 38.1mm OD x 5.2mm OAL
|
NH
3/16" x 13/32" ID x 1-1/2" OD
|
| 25. |
249100
|
[1] |
WASHER,0.78" ID x 1.25" OD x 0.06" Thk
|
NH
Special
|
| 26. |
122257
|
[3] |
WASHER,61.9mm ID x 77.79mm OD x 1.2mm Thk
|
NH
2-3/8"
|
| 27. |
87020910
|
[4] |
SPACER,10.4mm ID x 19mm OD x 8.9mm Thk
|
PA
|
| 28. |
140045
|
[12] |
BELLEVILLE WASHER,M10 Bolt Size x 22mm OD x 1.6mm Thk
|
NH
|
| 29. |
322359
|
[2] |
BELLEVILLE WASHER,M20 Bolt Size x 40mm OD x 3.2mm Thk
|
NH
|
| 32. |
425-106
|
[2] |
NUT,3/8"-16, Cl 5
|
CAS
Superseded by part number: 9628503
|
| 33. |
825-2410
|
[12] |
FLANGE NUT,M10 x 1.5, Flg, Cl 8
|
CAS
Superseded by part number: 9804278, 87778057
|
| 37. |
280315
|
[1] |
GROOVED PIN,4.76mm OD x 25.4mm L
|
NH
|
| 38. |
86544809
|
[2] |
LOCK PIN,9.53mm OD x 76.2mm L, Slotted
|
NH
|
| 39. |
32-1220
|
[2] |
COTTER PIN,3/16" x 1 1/4"
|
CAS
Superseded by part number: 87398
|
