纽荷兰零件查询(CV2500) - VIBRATORY ROLLER (02-001-00[01]) - ENGINE - ENGINE MOUNTING New Holland Constructuion
广数供应链运营团队, 14 02月, 2025，浏览：
478 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | ND028621 | [1] | SUPPORT | STA |
| 2. | ND028625 | [1] | SUPPORT | STA |
| 3. | ND104717 | [2] | SUPPORT | STA |
| 4. | ND046074 | [2] | RUBBER MOUNTING | STA |
| 5. | ND029756 | [1] | SUPPORT | STA |
| 6. | ND029753 | [1] | SUPPORT | STA |
| 12. | ND031279 | [1] | FLANGE | STA |
| 13. | ND049398 | [6] | PLATE | STA |
| 18. | ND028629 | [2] | BRACKET | STA |
| 32. | ND104747 | [1] | HOLDER | STA |
| 36. | ND090794 | [1] | ENGINE,6 Cylinders, W/ Turbocharger | STA |
| 45. | ND021187 | [2] | BOLT | STA |
| 47. | ND021195 | [12] | BOLT | STA |
| 51. | ND021311 | [18] | BOLT | STA |
| 52. | ND021312 | [8] | BOLT | STA |
| 53. | ND021313 | [1] | BOLT | STA |
| 54. | ND021211 | [16] | BOLT | STA |
| 56. | ND023846 | [2] | SCREW | STA Superseded by part number: ND021327 |
| 64. | ND034086 | [36] | NUT | STA |
| 71. | ND035941 | [12] | WASHER | STA |
| 73. | ND029267 | [34] | WASHER | STA |
| 74. | ND035943 | [2] | WASHER | STA |
| 75. | ND029253 | [2] | WASHER | STA |
| 86. | ND091164 | [1] | SPACER | STA |
| 95. | ND064129 | [2] | RUBBER MOUNTING | STA |
| 100. | ND066152 | [1] | WIRE HARNESS | STA |
| 112. | ND062019 | [2] | CLAMP | STA |
| 113. | ND064807 | [2] | CLAMP | STA |
