凯斯零件查询(RB454) - CASE IH ROUND BALER (7/07-1/14) (13.910) - 1.8M WIDE PICKUP, WINDGUARD, ONE-PIECE, NORTH AMERICA Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
322 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 2. |
87367931
|
[2] |
ARM
|
BEL
|
| 4. |
86599418
|
[3] |
FINGER
|
PA
Middle Superseded by part number: 87355310
|
| 5. |
86631509
|
[2] |
CHAIN
|
NH
26-3/4" Superseded by part number: 87055684
|
| 6. |
87054239
|
[1] |
WINDGUARD
|
PA
|
| 7. |
86599424
|
[4] |
FINGER
|
PA
Outside Superseded by part number: 87355309
|
| 8. |
87056822
|
[2] |
PIN
|
PA
|
| 9. |
86621502
|
[7] |
CLIP
|
NH
|
| 10. |
86603107
|
[4] |
NUT
|
PA
Square
|
| 11. |
197559
|
[2] |
CHAIN,9" L
|
NH
|
| 12. |
133095
|
[2] |
SPACER,10.32mm ID x 15.85mm OD x 7.9mm L
|
NH
|
| 13. |
80702
|
[8] |
WASHER,0.44" ID x 1" OD x 0.08" Thk
|
NH
|
| 15. |
9804262
|
[2] |
BOLT,M10 x 39.2mm, Cl 8.8
|
NH
Superseded by part number: 9840672
|
| 19. |
88546
|
[2] |
BOLT,Hex, 3/8" - 16 x 2 1/4", Gr 5
|
NH
|
| 20. |
374892
|
[4] |
CARRIAGE BOLT,M10 x 1.5 x 40mm, Cl 8.8
|
NH
|
| 22. |
80756
|
[2] |
COTTER PIN,1/8" x 3/4"
|
NH
|
| 24. |
100037
|
[6] |
LOCK NUT,M10 x 1.5, Cl 8
|
NH
|
| 26. |
88902
|
[2] |
NUT,3/8"-16
|
NH
|
