现代零件查询R170W-7 UPPER HYD PIPING 1(ADJUST BOOM, #0022-)EPC Hyundai
广数供应链运营团队, 14 02月, 2025，浏览：
948 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| . |
@
|
[1] |
UPPER HYD PIPING 1
|
|
| 2. |
31N5-10312
|
[2] |
PIPE ASSY
|
|
| 5. |
P930-127019
|
[1] |
HOSE ASSY-ORFS 0X90
|
|
| 6. |
P930-127016
|
[2] |
HOSE ASSY-ORFS 0X90
|
|
| 6. |
P930-127016
|
[1] |
HOSE ASSY-ORFS 0X90
|
|
| 7. |
P930-127018
|
[2] |
HOSE ASSY-ORFS 0X90
|
|
| 7. |
P930-127021
|
[1] |
HOSE ASSY-ORFS 0X90
|
|
| 8. |
P930-127017
|
[1] |
HOSE ASSY-ORFS 0X90
|
|
| 8. |
P930-127017
|
[2] |
HOSE ASSY-ORFS 0X90
|
|
| 9. |
P913-127035
|
[4] |
HOSE ASSY-ORFS 0X0
|
|
| 10. |
31N5-10260
|
[4] |
HOSE ASSY
|
|
| 10. |
31N5-10260
|
[2] |
HOSE ASSY
|
|
| 14. |
31N4-12200
|
[2] |
CLAMP-PIPE
|
|
| 15. |
31N5-10340
|
[1] |
BRACKET
|
|
| 16. |
31N5-10380
|
[1] |
BRACKET-LH,MANIFOLD
|
|
| 17. |
31N5-10390
|
[1] |
BRACKET-RH,MANIFOLD
|
|
| 18. |
35EA-12500
|
[1] |
MANIFOLD-LH
|
|
| 19. |
35EA-12510
|
[1] |
MANIFOLD-RH
|
|
| 21. |
X500-110004
|
[8] |
CONNECTOR-ORFS
|
|
| 22. |
X511-112548
|
[2] |
CONNECTOR-LONG,ORFS
|
|
| 23. |
X511-112546
|
[1] |
CONNECTOR-ORFS
|
|
| 24. |
X511-116546
|
[1] |
CONNECTOR-LONG,ORFS
|
|
| 25. |
X511-116548
|
[2] |
CONNECTOR-LONG,ORFS
|
|
| 34. |
S017-100602
|
[1] |
BOLT-HEX
|
|
| 35. |
S017-100852
|
[1] |
BOLT-HEX
|
|
| 36. |
S037-103022
|
[2] |
BOLT-W/WASHER
|
|
| 37. |
S037-123052
|
[10] |
BOLT-W/WASHER
|
|
| 38. |
S207-101002
|
[1] |
NUT-HEX
|
|
| 39. |
S403-101002
|
[2] |
WASHER-PLAIN
|
|
| 40. |
S411-100002
|
[2] |
WASHER-SPRING
|
|
| 41. |
S621-018001
|
[20] |
O-RING,ORFS
|
|
| 43. |
S631-024004
|
[15] |
O-RING
|
|
| 44. |
S631-029004
|
[3] |
O-RING
|
|
| 45. |
P220-110105
|
[4] |
PLUG-HEX
|
|
| 46. |
XKBF-00095
|
[2] |
RELIEF VALVE-OVERLOAD
|
|
| 48. |
P173-120102
|
[8] |
FLANGE-SPLIT
|
|
| 49. |
Y171-019004
|
[4] |
O-RING
|
|
| 50. |
S109-100356
|
[16] |
BOLT-SOCKET
|
|
| 50. |
S109-100306
|
[16] |
BOLT-SOCKET
|
|
| 52. |
31N5-53060
|
[2] |
HOSE ASSY
|
|
| 53. |
P930-127020
|
[1] |
HOSE ASSY-ORFS 0X90
|
|
