凯斯零件查询(RB454) - CASE IH ROUND BALER (7/07-1/14) (13.970) - 2M WIDE PICKUP, WINDGUARD MOUNTING Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
251 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 2. |
87057819
|
[2] |
ARM
|
PA
Superseded by part number: 87367931
|
| 5. |
86631509
|
[2] |
CHAIN
|
NH
26-3/4" Superseded by part number: 87055684
|
| 6. |
87043833
|
[1] |
WINDGUARD
|
NH
|
| 8. |
87056822
|
[2] |
PIN
|
PA
Klik
|
| 12. |
86603107
|
[4] |
NUT
|
PA
Square
|
| 14. |
133095
|
[2] |
SPACER,10.32mm ID x 15.85mm OD x 7.9mm L
|
NH
|
| 15. |
495-21044
|
[8] |
WASHER,3/8"
|
CAS
Superseded by part number: 87779090, 80702
|
| 19. |
413-636
|
[2] |
BOLT,Hex, 3/8" - 16 x 2-1/4", Gr 5
|
CAS
Superseded by part number: 88546, 72187212
|
| 20. |
811-10040
|
[4] |
CARRIAGE BOLT,Sht Sq Nk, M10 x 1.5 x 40mm, Cl 8.8
|
CAS
Superseded by part number: 374892
|
| 22. |
844-10030
|
[2] |
BOLT,Hvy Hex, M10 x 30mm, Cl 8.8
|
CAS
Superseded by part number: 9840672
|
| 24. |
832-46410
|
[6] |
NUT,M10 x 1.5, Cl 8
|
CAS
Superseded by part number: 100037
|
| 26. |
231-4146
|
[2] |
NUT,3/8"-16, GB
|
CAS
Superseded by part number: 88902
|
