现代零件查询R170W-7 PILOT HYD PIPING(CONTROL 1, #0430-)EPC Hyundai
广数供应链运营团队, 14 02月, 2025，浏览：
818 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| . |
@
|
[1] |
PILOT HYD PIPING
|
|
| 1. |
31N6-25200
|
[1] |
RCV SUB ASSY-LH
|
|
| 1. |
31N6-26200
|
[1] |
RCV LEVER SUB ASSY-LH
|
|
| 1-1. |
@
|
[1] |
RCV LEVER
|
|
| 1-2. |
X500-110001
|
[5] |
CONNECTOR-ORFS
|
|
| 1-3. |
31N6-25060
|
[1] |
FILTER-LAST GUARD
|
|
| 1-4. |
S631-011004
|
[6] |
O-RING
|
|
| 1-5. |
S621-011001
|
[6] |
O-RING
|
|
| 4. |
31N4-20080
|
[1] |
RCV LEVER
|
|
| 5. |
31N6-25100
|
[1] |
CROSS ASSY
|
|
| 5-1. |
31N6-25040
|
[2] |
CROSS-BULKHEAD TYPE
|
|
| 10. |
X410-042024
|
[2] |
HOSE ASSY-ORFS 0X45
|
|
| 11. |
X410-042026
|
[2] |
HOSE ASSY-ORFS 0X45
|
|
| 14. |
X410-042039
|
[4] |
HOSE ASSY-ORFS 0X45
|
|
| 15. |
X420-042058
|
[1] |
HOSE ASSY-ORFS 0X90
|
|
| 16. |
X420-042065
|
[1] |
HOSE ASSY-ORFS 0X90
|
|
| 17. |
31E7-0309
|
[1] |
CLAMP-HOSE
|
|
| 19. |
31M6-51061
|
[1] |
SHIM(3.2T)
|
|
| 20. |
31N6-25060
|
[1] |
FILTER-LAST GUARD
|
|
| 21. |
X511-104513
|
[2] |
CONNECTOR-LONG,ORFS
|
|
| 22. |
X500-110001
|
[1] |
CONNECTOR-ORFS
|
|
| 29. |
S631-011004
|
[4] |
O-RING
|
|
| 32. |
S621-011001
|
[6] |
O-RING
|
|
| 32. |
S621-011001
|
[12] |
O-RING
|
|
| 35. |
S035-083526
|
[2] |
BOLT-W/WASHER
|
|
| 37. |
S035-063046
|
[4] |
BOLT-W/WASHER
|
|
| 39. |
S037-102046
|
[3] |
BOLT-W/WASHER
|
|
| 40. |
31N6-25010
|
[1] |
TERMINAL ASSY
|
|
| 40-1. |
31N6-25030
|
[1] |
SHUTTLE-5 PORT
|
|
| 40-1-1. |
S621-011001
|
[3] |
O-RING
|
|
| 40-1-2. |
X500-110001
|
[3] |
CONNECTOR-ORFS
|
|
| 40-2. |
X540-120001
|
[6] |
CONNECTOR-ORFS
|
|
