现代零件查询R170W-7 PILOT HYD PIPING(BASE 2, 2-BLOCK, OPT)EPC Hyundai
广数供应链运营团队, 14 02月, 2025，浏览：
713 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 3. |
31E3-0017
|
[1] |
FILTER-LINE
|
|
| 3-2. |
31E3-0018
|
[1] |
ELEMENT-LINE FILTER
|
|
| 4. |
31E3-3187
|
[1] |
ACCUMULATOR
|
|
| 6. |
X500-110001
|
[2] |
CONNECTOR-ORFS
|
|
| 9. |
31N6-24200
|
[1] |
CONNECTOR
|
|
| 10. |
X520-110001
|
[2] |
ELBOW-90,ORFS
|
|
| 11. |
X520-110002
|
[1] |
ELBOW-90,ORFS
|
|
| 12. |
X520-110003
|
[1] |
ELBOW-90,ORFS
|
|
| 17. |
31N6-22400
|
[1] |
ADAPTOR
|
|
| 19. |
X820-045151
|
[1] |
TEE-R/TYPE,ORFS
|
|
| 23. |
31EK-11130
|
[4] |
COUPLING-SCREW
|
|
| 28. |
X500-110003
|
[2] |
CONNECTOR-ORFS
|
|
| 30. |
X520-110004
|
[1] |
ELBOW-90,ORFS
|
|
| 34. |
X820-125452
|
[1] |
TEE-R/TYPE,ORFS
|
|
| 35. |
S035-082546
|
[2] |
BOLT-W/WASHER
|
|
| 41. |
S621-014001
|
[2] |
O-RING
|
|
| 42. |
S621-018001
|
[4] |
O-RING
|
|
| 44. |
S631-011004
|
[9] |
O-RING
|
|
| 45. |
S631-014004
|
[2] |
O-RING
|
|
| 46. |
S631-018004
|
[4] |
O-RING
|
|
| 47. |
S631-024004
|
[2] |
O-RING
|
|
| 51. |
P930-122013
|
[1] |
HOSE ASSY-ORFS 0X90
|
|
| 52. |
P930-122012
|
[1] |
HOSE ASSY-ORFS 0X90
|
|
| 59. |
X420-042007
|
[3] |
HOSE ASSY-ORFS 0X90
|
|
| 60. |
X420-042009
|
[1] |
HOSE ASSY-ORFS 0X90
|
|
| 60. |
X420-042009
|
[1] |
HOSE ASSY-ORFS 0X90
|
|
| 72. |
P930-062009
|
[1] |
HOSE ASSY-ORFS 0X90
|
|
| 73. |
P910-082018
|
[1] |
HOSE ASSY-ORFS 0X0
|
|
| 80. |
S621-011001
|
[6] |
O-RING
|
|
